Technical data

Standards and operating conditions

6 Technical data
6.1 Standards and operating conditions
Conformities
CE
EAC
RoHS 2
Approvals
UL
Energy efficiency
Class IE2
Degree of protection
IP20
Type 1
Open type
Insulation resistance
Overvoltage category III
Overvoltage category II
Control circuit isolation
Safe mains isolation by double/
reinforced insulation
Protective measures against
Short circuit
Earth fault
Overvoltage
Motor stalling
Motor overtemperature
Leakage current
> 3.5 mA AC, > 10 mA DC
Mains switching
3-time mains switching in 1 min
Starting current
≤ 3 x rated mains current
Mains systems
TT
TN
IT
Operation on public supply systems
Implement measures to limit the radio
interference to be expected:
< 1 kW: with mains choke
> 1 kW at mains current ≤ 16 A:
without additional measures
30
2014/35/EU Low-Voltage Directive
2014/30/EU EMC Directive (reference: CE-typical drive system)
TR TC 004/2011 Eurasian conformity: safety of low voltage equipment
TP TC 020/2011 Eurasian conformity: electromagnetic compatibility of
technical means
2011/65/EU Restrictions for the use of specific hazardous materials
in electric and electronic devices
UL 61800-5-1 for USA and Canada (requirements of the CSA 22.2
No. 274)
0.25 kW ... 22 kW (30 kW ... 45 kW in preparation)
EN 50598-2 Reference: Lenze setting (switching frequency 8 kHz
variable)
EN 60529
NEMA 250 Protection against contact
only in UL-approved systems
EN 61800-5-1 0 ... 2000 m a.m.s.l.
above 2000 m a.m.s.l.
EN 61800-5-1
Earth fault strength depends on the operating status
PTC or thermal contact, I²xt monitoring
EN 61800-5-1 Observe regulations and safety instructions!
Cyclic, without any restrictions
Voltage to earth/ground: max. 300 V
Apply the measures described for IT systems!
IT systems are not relevant for UL-approved systems
The machine or plant manufacturer is responsible for
compliance with the requirements for the machine/
plant!
EN 61000-3-2
