Technical data

2.1

General data and operating conditions

General data
Conformity and approval
Conformity
CE
Protection of persons and equipment
Enclosure
Earth leakage current
Total fault current
Equipotential bonding
Protective insulation of
control circuits
Insulation resistance
Protective measures
Service switch
Design
Tripping current
EMC
Noise emission
Noise immunity
EDKLCFH1134−EPM DE/EN 1.0
General data and operating conditions
73/23/EEC Low−Voltage Directive
EN 60529 IP54
All unused connectors must be covered with plugs or a
protective cover.
EN 61800−5−1 > 3.5 mA
< 100 mA
The use of residual−current circuit breakers 300 mA is possible
(RCCB, type B).
M6 threaded bolts on housing exterior for connection of a 16
mm@ protective earth cable
EN 61800−5−1 Safe isolation from mains by double (reinforced) insulation
EN 61800−5−1 Site altitude < 2000 m: Overvoltage category III
Site altitude > 2000 m: Overvoltage category II
Short circuit on the motor side, earth fault when switching on
the mains and during operation, motor overtemperature
(input for PTC or thermal contact, I
Rotary switch, triple locking
Feedback contact for status message and reset offault
message (TRIP reset)
16 A (controllers 0,75 ... 3 kW)
25 A (controllers 5 ... 11 kW)
EN 61800−3 Cable−guided: categoriy C2 with Lenze system cables up to
20 m motor cable length
EN 61800−3 Category C3
l
Technical data
Observe regulations and safety
instructions!
2
t monitoring)
