Lenze i500 Montage- Und Einschaltanleitung Seite 53

Inverter
Cable installation in
compliance with
Laying system
Operation
Fuse
Characteristic
Max. rated current
Circuit breaker
Characteristic
Max. rated current
Operation
Fuse
Characteristic
Max. rated current
Circuit breaker
Characteristic
Max. rated current
Earth-leakage circuit
breaker
Mains connection
Connection
Connection type
Min. cable cross-section
Max. cable cross-section mm²
Stripping length
Tightening torque
Required tool
Motor connection
Connection
Connection type
Min. cable cross-section
Max. cable cross-section mm²
Stripping length
Tightening torque
Required tool
PE connection
Connection
Connection type
Min. cable cross-section
Max. cable cross-section mm²
Stripping length
Tightening torque
Required tool
A
A
A
A
mm²
mm
Nm
mm²
mm
Nm
mm²
mm
Nm
Electrical installation
3-phase mains connection 480 V
I55AE322F
EN 60204-1
B2
without mains choke
gG/gL or gRL
63
B
63
with mains choke
gG/gL or gRL
63
B
63
≥ 300 mA, type B
X100
Screw terminal
1.5
35
18
3.8
0.8 x 5.5
X105
Screw terminal
1.5
35
18
3.8
0.8 x 5.5
PE
PE screw
1.5
25
16
4
PZ2
Mounting 4
17
