CARDIOSTRONG TX90 Montage- Und Bedienungsanleitung Seite 40

Nr. Bezeichnung (ENG)
86 Flat washer
87 Nylon nut
88 Computer set
89A Decorative cover for computer
89B Back computer cover
90A Upper computer cover
90B Lower computer cover
91 Button plate
92 Upper cable for button on side
bar
93 Handle pulse cable
94 Button overlay
95 Right speaker
96 LED light connecting plate
97 Backlight plate
98 Audio cable
99L Lower cable for button on left
bar
99R Lower cable for button on right
bar
100 Sensor cable
101 Magnetic loop
102 Safety key
103 Left speaker
104 Inner case of safety key
105 Safety key board
106 Safety clip
107 Emergency stop pin
108 Tablet pad
110 Cable for emergency stop
function
40
Hrst. Teilenummer
55105-1-1208-DA
55205-1-2005-DA
261D8-2-1700-B0
261D8-6-1749-B0
261D8-6-1748-B0
261D8-6-1702-B0
261D8-6-1703-B0
261D8-6-1756-B0
261D8-6-1589-01
261D8-6-1785-00
261D8
261D8-6-1761-00
261D1-6-1744-00
261D2-6-2405-01
81000-6-2555-B0
261D8-6-1582-00
261D8-6-1592-00
26100-6-1795-00
26100-6-1079-00
26200-6-1732-R0
261D8-6-1722-01
26100-6-1734-B0
26200-6-1733-B0
26200-6-1793-R0
26100-6-1731-C1
261D8-6-1777-B0
261D8-6-1736-00
Spezifikation
D12*D5.2*0.8T
M5*0.8*5T
202*49*23
202*178*37
454.2*348*44.3
454.2*344.5*60.5
267.2*95.3*13.5
500L
1000L
B00202050,4Ω 3W，100L
PA-AA01170-K5
190*25
250L
800L
800L
GS003-P2.5F-1200mm-
26AWG
D31*16
78.6*35*18.2
B00202050,4Ω 3W，300L
39*15*13.3
74*45*7
830L
21*18*1.5T
450L
TX90
Anz.
4
2
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
