Spezifikation - CARDIOSTRONG TX90 Montage- Und Bedienungsanleitung

Nr. Bezeichnung (ENG)
56 Folding unit
57 Locking bracket
58 Inner tube of folding unit
59 Spring
60 Cylinder
61 Allen bolt
62 Hollow cap
63 Allen bolt
64 Allen screw
65 Nylon nut
66 Flat washer
67 Allen bolt
68 Bushing
69 Plastic washer
70 Incline motor
71 Flat washer
72 Spring washer
73 Nylon nut
74 Allen bolt
75 Allen bolt
76 Flat washer
77A Upper cover for motor
77B Lower cover for motor
78 Decorative cover for motor
79 rear cover
80 Power supplier board
81 Switching mode power supplier
82 overcurrent protector
83 Socket
84 Buffer
85 Screw
Hrst. Teilenummer
26100-3-1650-J1
26100-3-1660-J0
26100-6-1652-N1
58003-6-1069-N0
26100-6-1661-B0
50308-5-0030-F0
26100-6-1676-B0
50308-5-0050-F3
54006-5-0035-F3
55206-1-2006-FA
55108-1-1810-W8
50310-5-0035-F3
58002-6-1104-UC0
55110-1-2404-BF
26100-6-1975-00
55110-1-2020-FA
55110-2-1730-FA
55210-1-2010-FA
54010-8-0065-F4
54010-8-0050-F4
55110-1-3030-FA
26100-6-2401-B0
26100-6-2402-B0
261D8-6-2403-B0
261D8-6-2406-B0
26100-6-2414-B0
26100-6-2411-00
26100-6-2412-00
26100-6-2413-00
55308-4-0020-G9
53329-2-0009-D0

Spezifikation

20*20*1.5T*440L
D1.5*14.6L
760*53KG
M8*1.25*30
30*30*65L
M8*1.25*50
M6*1.0*35L
M6*1.0*6T
D18*D8.5*1.0T
M10*35L
D28*D10*9.2
D10*D24*0.4T
JS11-B
D20xD11x2T
D17.8*D10.2*3.0T
M10x1.5x10T
M10*1.5*65L
M10*1.5*50L
D30*D10*3.0T
725*416.6*120.4
729*80*54.8
323.9*87.7*22.6
729.5*153.6*135
130*45*6T
10A
D10.5*20L
ST2.9x9.5L
Anz.
1
1
1
1
1
2
1
1
1
1
4
4
4
4
1
8
6
10
1
1
2
1
1
1
1
1
1
1
1
2
36
39
