6. Spare parts / Replacing spare parts
6.1. Filter
CA BASIC 2000
The respiratory power unit is equipped with a high
efficiency particle filter of class PSL.
The filter must be regularly checked (see Air Flow
Test - chapter 4.2.) and replaced.
Make sure that the new filter is within its expiry
date, unused and not evidently damaged.
From the hygienic point of view
working time of a filter is 180 hours and should not
be exceeded.
It is prohibited to clean the filter by any procedure!
The particle filter can be used with a Pre-filter or
with an Odour filter which removes the unwanted
smell of harmless gases.
CHANGING THE FILTER OF CA BASIC 2000
see picture supplement no.1
pict. 1A :
Removing the filter cover: Face the silver filter cover
towards you. Put your index fingers and middle
fingers into the gaps between the body of the unit
and the filter cover on both sides.
pict. 1B :
Rest your thumbs on the top of the silver filter
cover. Then pull your fingers placed in the gaps
outwards lifting the filter cover off the unit.
ATTENTION! It is strictly forbidden to use any tools
to uncover the filter.
CA CHEMICAL
- Selection of the filter acc. to the type of contamination
Ordering code Filter type *
50 00 48 PSL
50 01 56 A
50 01 57 APSL
50 01 67 ABPSL
50 01 68 ABEKPSL
6.2. Batteries
NOTE ! Batteries are delivered
batteries must be charged before they are used for
the first time. The battery can be charged
separately or on the blower unit.
The charger must not be used for any other
purpose than that for which it was manufactured.
Do not charge the battery in a potentially explosive
atmosphere. The battery charger is intended for
__________________________________________________________________________________
the maximum
Colour code
White
Brown
Brown
White
Brown
Grey
White
Brown
Grey
Yellow
Green
White
* Filtres for Clean-AIR blower units are marked acc. to EN 12 941
The grid needn´t list all available types of filters, contact your supplier for complete current offer.
discharged. All
pict. 1C :
To remove the filter, take it out while rotating it.
Clean the unit from dust.
pict. 1D :
Inserting a new filter: If you are using a prefilter or
an odourfilter, fix it around the new filter as tight as
possible and stick the ends together using the sticky
tape which is prepared on the prefilter/odourfilter.
Put the filter back into position using the same
rotating motion and gently push until it fits well on
the body of the unit . Cover the filter with the silver
filter cover. Pay special attention to snap the cover
properly (on both sides).
CA CHEMICAL
The blower units CACH FC and CACH DF may be
used only with all three filters installed.
Stricly use three identical filters at one go (one set
of 3 filters).
CHANGING THE FILTER OF CA CHEMICAL
see picture supplement no.2
pict. 2A :
Dismount the filters from the unit by unscrewing
them one by one.
ATTENTION ! Check that the new filters are within
the expiry date and that the packaging is
undamaged and sealed. Also check that the rubber
sealing in the thread of the unit is not damaged and
clean all the sealings.
pict. 2B :
Mount the new filters onto the blower unit one by
one. Screw all 3 filters tightly to prevent leaks.
Type of contaminant
Solid and liquid particles (Aerosols)
Organic gases and vapours with boiling point >65°C
Organic gases and vapours with boiling point >65°
Solid and liquid particles (Aerosols)
Organic gases and vapours with boiling point >65°
Inorganic gases and vapours such as Chlorine, hydrogen sulfid (H2S),
hydrogen cyanide (HCN)
Solid and liquid particles (Aerosols)
Organic gases and vapours with boiling point >65°
Inorganic gases and vapours such as Chlorine, hydrogen sulfid (H2S),
hydrogen cyanide (HCN),
sulphur dioxide (SO2)
ammonia (NH3)
Solid and liquid particles (Aerosols)
indoor use. It must be protected against damp. The
charger controls the charging automatically. After
the battery has been charged, the charger switches
to the trickle charging regime and keeps the battery
fully charged. The charging time is 10 to 14 hours
depending on the type of battery.
