5. Models

2-Strang
Model
ohne Pumpe
with Grundfos UPM3 Hybrid 25-70 PWM
with Grundfos UPM3 Solar 25 - 145 PWM
with Wilo Yonos Para ST 25/1-7 PWM
Wie zuvor, jedoch mit im Vorlauf montiertem Permanententlüfter für die stetige Abscheidung von Luft
ohne Pumpe
with Grundfos UPM 3 Hybrid 25-70 PWM
with Grundfos UPM3 Solar 25 - 145 PWM
with Wilo Yonos Para ST 25/1-7 PWM
The installation and assembly instructions of the pump manufacturers must be observed.
We recommend the solar regulators Basic Pro, Energy Pro, or Maximal Pro, as well as the appropriate flow transmitter (see page 38).
Accessories: Solar controller
Model
Basic Pro
Digital differential temperature controller for thermal solar systems (1 collector field, 1 accumulator); fully graphic, backlighted monochro-
me screen, operation through rotary/push switch and ESC button; 3 inputs for PT 1000 sensor; analog or PWM output for high-efficiency
pump; speed control; one already configured hydraulic scheme; 1 triac output; fault monitoring; manual mode possible; collector protection
function; commissioning / service assistant; fixed-T and delta-T control; tube-collector function; after-run time for outputs; frost protection;
sensor monitoring; monitoring of output parameters; hour counter for outputs; solar yield measurement for pump control incl. data output;
solar yield measurement without flow rate meter possible; scope of delivery incl. 2 universal temperature sensors PT 1000
Pump control via block modulation, PWM or 0-10 V signal
Energy Pro
Like solar regulator Basic Pro, however with fully-graphical, dimmable, backlighted colour screen; 4 inputs for PT 1000 sensors; 2 triac
outputs; floating contact; flow rate measurement function; SD-card reader; USB connection; 20 preconfigured hydraulic schemes; 2 collec-
tor fields and 1 accumulator / 1 collector field and 2 accumulators; solar heating support; remote access; soft charging; disable recharge
function; thermostat and temperature comparison function; accumulator priority charging; holiday function; anti-legionella function; heating
return increase; bypass function and charge zone control; scope of delivery incl. 2 universal temperature sensors PT 1000 and analyzer
software; control for secondary pump with separating systems; swimming pool heating
Pump control via block modulation, PWM or 0-10 V signal
Article no.
45804 EA
45804.9
45804.186
45804.9 WI
45804.5 EA
45804.10
45804.586
45804.10 WI
Model Article no.
45111.56
45111.76
