Invacare Aquatec Ocean Servicehandbuch Seite 9

Castors
Check for
1 Sluggish or damaged swivel bearings
2 Sluggish castor wheel (bearings)
3 Damaged castor wheel running
surface
4 Castor fork damage
5
Securely tightened connecting bolts
to the frame
24" wheels (Ocean / Ocean Ergo)
Check for
1
Damage to the 24" wheels
2
Correct function of the brake (wheel
must lock)
3
Correct assembly of the 24" wheels,
the locking pins protrude past the
end of the hub to fully release
Headrest (Ocean VIP / Ocean Dual VIP / Ocean E-VIP / Ocean VIP Ergo / Ocean Dual VIP Ergo)
Check for
1 Damage to the headrest hardware
(cracks, sharp edges)
2 Damage to the headrest pad
Seat tilting mechanism (Ocean VIP / Ocean Dual VIP / Ocean VIP Ergo / Ocean Dual VIP Ergo)
Check for
1
Damage to the Bowden wire system
or cable shells
2
Damage to the activation handle
3 Function of tilting and fixation of
the position, easy tilting and secure
locking of the position is mandatory.
4
Gas Spring damage
5
Release mechanism damage
1640651-A
Troubleshooting action
Replace the complete castor with a new one, 5.5
Replacing the castors, page 13
Replace connecting bolts with new tread locking
adhesive.
Troubleshooting action
Replace the 24" wheels, see mounting instruction.
Carry out brake adjustment or replace the brakes,
see mounting instruction.
Carry out hub adjustment or replace the hub or axle,
see mounting instruction.
Troubleshooting action
Replace the headrest, see mounting instruction.
Replace the headrest pad, see mounting instruction.
Troubleshooting action
Replace the Bowden wire system, 5.11 Replacing
the Bowden cable for seat tilting (Ocean VIP Ergo /
Ocean Dual VIP Ergo), page 24 / 5.10 Replacing the
gas spring — release mechanism — Bowden cable
for seat tilting (Ocean VIP / Ocean Dual VIP), page 22
Replace the activation handle, see user manual.
Adjust the Bowden wire, 5.11 Replacing the Bowden
cable for seat tilting (Ocean VIP Ergo / Ocean Dual
VIP Ergo), page 24 / 5.10 Replacing the gas spring —
release mechanism — Bowden cable for seat tilting
(Ocean VIP / Ocean Dual VIP), page 22.
Replace the gas spring, 5.11 Replacing the Bowden
cable for seat tilting (Ocean VIP Ergo / Ocean Dual
VIP Ergo), page 24 / 5.10 Replacing the gas spring —
release mechanism — Bowden cable for seat tilting
(Ocean VIP / Ocean Dual VIP), page 22.
Replace the release mechanism, 5.11 Replacing the
Bowden cable for seat tilting (Ocean VIP Ergo /
Ocean Dual VIP Ergo), page 24 / 5.10 Replacing the
gas spring — release mechanism — Bowden cable for
seat tilting (Ocean VIP / Ocean Dual VIP), page 22.
Reconditioning
OK
☐
☐
☐
☐
☐
OK
☐
☐
☐
OK
☐
☐
OK
☐
☐
☐
☐
☐
9
