Invacare Aquatec Ocean Servicehandbuch Seite 8

Aquatec® Ocean/Ocean Ergo family
Frame (all frame parts, tubes incl. backrest)
Check for
1 Mechanical damage of the frame
parts (cracks, fractures)
2 Mechanical damage of the antitipper
(Ocean Dual VIP / Ocean Dual VIP
Ergo)
Side parts
Check for
1
Mechanical damage
Seat
Check for
1
Seat damage (cracks, sharp edges)
2
Wobbling, less stable seating
3
Damaged snaps on the underside
Backrest cover
Check for
1
Backrest cover damage (cracks, open
seams, damaged buckles)
Footrest
Check for
1
Foot plate damage (cracks, sharp
edges)
2
Damage to the foot rest fixation at
the frame (Ocean VIP / Ocean E-VIP)
3
Damage to the tubes
4
Damage to the attachment clips
Armrest
Check for
1
Damage to the armrest tubes or
armrest holders (cracks, sharp edges)
2
Damage to the armrest pads (cracks,
sharp edges)
8
Troubleshooting action
Discard frame and replace with new one, see 5.8
Replacing the side parts (Ocean VIP Ergo / Ocean
Dual VIP Ergo), page 16 respectively the user manual.
Otherwise discard the product.
Replace the antitipper, see user manual.
Troubleshooting action
Discard the side parts and replace with new one,
see 5.8 Replacing the side parts (Ocean VIP Ergo /
Ocean Dual VIP Ergo), page 16 respectively the user
manual.
Troubleshooting action
Replace the seat, see user manual.
Troubleshooting action
Replace the backrest cover, see user manual.
Troubleshooting action
Replace the foot plates, 5.4 Replacing the foot
plates, page 12
Replace the foot rest fixation, 5.3 Replacing the
footrest holder (Ocean VIP / Ocean Dual VIP / Ocean
E-VIP), page 12
Replace the complete footrest with new one, see
user manual.
Replace the footrest attachment clips with new ones. ☐
Troubleshooting action
Replace the armrest with new one, 5.2 Replacing
the armrest, page 11
Replace the armrest pad, 5.2.1 Replacing the armrest
pad, page 11
OK
☐
☐
OK
☐
OK
☐
☐
☐
OK
☐
OK
☐
☐
☐
OK
☐
☐
1640651-A
