10. Specifications
10.
Specifications
CPP7000-X
Pressure range
Pressure transmission medium
Reservoir
Druckanschlüsse
Test connection
Distance between test connections
Piston of the comparison test pump
Piston diameter
Displacement per revolution
Overall displacement
Material
Cylinder
Piston
Piping
Sealings
Permissible operating temperature
Instrument base
Stationary mounting
Dimensions (L x W x H)
Weight
For further specifications see WIKA data sheet CT 91.13 and the order documentation.
WIKA Operating Instruction, model CPP7000-X
0 ... 7,000 bar
(0 ... 100,000 psi)
Sebacate oil
250 cm³
2 x knurled nut G ¾ female, freely rotating with sealing
cone, incl. interchangeable adapter to M16 x 1.5 male with
sealing cone
346 mm (13.6 in)
7.5 mm (0.3 in)
approx. 0.08 cm³
approx. 2.5cm³
Stainless steel
hardened stainless steel
1.4404 stainless steel, 6 x 2 mm (0.2 x 0.1 in)
NBR
18 ... 28 °C (64 ... 82 °F)
Stable base
460 x 445 x 265 mm (18.1 x 17.5 x 10.4 in)
32.5 kg (71.7 lbs.)
EN
27
