6. Commissioning, operation
First, install the matching threaded adapters on your device under test and reference
■
instrument.
Then connect the device under test and the reference instrument, including the installed
EN
■
threaded adapters, to the knurled nut of the test connections at the test pump. The free-
running knurled nut enables the orientation of the instruments. Firmly tighten the knurled nut
and the threaded adapter with an open-ended spanner in the desired clamping position. The
wrench width for the knurled nut and the threaded adapter is SW 36.
Threaded adapter
Knurled nut
Information
Additional sealing elements are not required. Sealing is performed purely metallic
using a sealing cone.
