Single booster
6 Li ad/dc 12/220v
Modellbau
Manual English B-Nr.: 88309
For LiPo or LiFe Batteries only.
Allows you to set the percentage of full charge of a LiPo or LiFe battery. Press[INC]or[DEC]to change
settings and press [SEL] shortly to confirm and to go to the next option.
LiPo/LiFe Discharge Cut-off voltage
For LiPo or LiFe Batteries only.
Press[INC]or[DEC]to change settings and press [SEL] shortly to confirm and to go to the next option.
For NiMH Batteries only.
Displays the cycle memory data.
This function can display the stored cycle data.
"D":Discharged capacity in mAh,
"C":Charged capacity in mAh.
Press and hold[ENT]button for 2sec to clear all cycle memory slots.
Press [SEL] shortly to go to the next option.
Press[INC]or[DEC]to change settings and press [SEL] shortly to confirm and to go to the first option
again
Press and hold the [SEL]button for 2 seconds to return to the main menu.
Press the [SEL]key shortly to scroll through the charge/discharge/balance (LiPo and LiFe batteries only)
menu:
Select memory profile Ml to M20(for all battery types) by pressing the [INC] or [DEC] button.
Select the previous used settings by selecting [ENT].
If you select a memory profile (M1 to M20)
The most frequently used charge settings can be stored to a specifically assigned memory slot. In normal
mode, previously used charge settings are used.
TO MODIFY CHARGE SETTINGS:
Press the [ENT]button ,the present charge setting will begin to flash. Then press the [INC]or[DEC] button
to change it in to the desired value while it continues to flash.
Select the number of cells and then select the charge current.
Then press the [ENT]button for 2seconds
Very Important: Be sure the numbers of cells is correct.
CELL COUNT RECONFIRM MESSAGE
The following message is displayed when the battery pack is at an unsafe voltage level or if the number of cells is
wrongly set. Double check the number of cells and connect again. If the number of cells is despite all warnings correct
press and hold the [ENT] button for 2 seconds to continue charging.
The LiPo charge sequence is shown below. Each step is especially designed for save LiPo and LiFe battery charging.
1. Checking the battery voltage.
The charger scans the battery pack
A. If the voltage is above 3,0V/cell (Lipo) or 2.0V/cell (LiFe) the charger will start the charge as set before.
26
