• 20 data memories
• 1~20 NiCd/NiMH Delta-peak adjustable (mV)
• 1~6 LiPo cells
• 1~6 LiFe cells
• 1-12S Pb batteries
• Charge current 200mA~10A (Max.80W by AC Power supply)
• Charge current 200mA~10A (Max.130W by DC Power supply)
• Discharger current 200mA~2A (Max. 8W)
• Timeout limit: The charging stops automatically after a preset period of time
• 3 different charge modes for LiPo and LiFe batteries: storage(50%), Fast Charge (1/10C) and full charge (100%)
• Adjustable discharge Cut-off voltage for Lipo, LiFe, Pb, NiCd and NiMH Batteries,
• All settings visible on the 2x16 backlight LCD screen while charging
• LiPo RECOVERY Mode : enables to recover low voltage LiPo and LiFe cells.
• Adjustable end of charge voltage for LiPo,LiFe battery
2. BATTERY ´RECOVERY MODE´ FUNCTION
The charger disposes of a special function, that allows to recover LiPo cells that are discharged too deeply
back to their normal voltage.
In principle , a LiPo cell whose voltage has dropped below 2.5V because of discharge or court circuit can't
be charged again.
The charger disposes of a special adapted 'recovery mode' charge program, which gradually can recover
the voltage of a LiPo cell, with the re-usage of this cell in view.
It is of considerably importance to start the recovery mode as soon as possible after an over discharge of a
LiPo element. The longer you wait to recover, the greater the possibilities are that the chemical structure of
the battery changes internally and the element cannot be brought to the right voltage again.
This charger has two recovery programs:
1. LiPo battery : charge with 200mA as voltage between 0.8VV ~ 2.5V,charge with 500mA as voltage
between 2.5V- 3.2V , charge with setting current above 3.2V
2. LiFe battery : charge with 200mA as voltage between 0.8V ~ 2.0V ,above 2.0V, charge with setting
current.
3. GERNAL SAFETY PRECAUTIONS
- Do not allow children to charge battery packs unless supervised by a responsible adult.
- Use only rechargeable batteries. This charger can not charge primary batteries such as "Heavy duty",
"Alkaline battery" or "Mercury battery".
- During operation, keep the charger well ventilated and never place it next to inflammables.
- This charger will be damaged if immersed in water or subjected to high level moisture. Do not use this
charger in the wet conditions in order to avoid electric shock or accident. This is very dangerous to both
the operator and the charger.
- The positive (red lead) and negative (black lead) terminals of the battery should be connected to the
charger terminals correctly. Do not reverse the positive and negative terminals, wrong connection will
damage the battery and will cause damage to
the charger.
-
Before you start to charge, please ensure you select correct charger settings. Double check if the battery
count and type match your charger setting. Make sure nothing goes wrong!
- The best current for charge/discharge is 1C (1 time of battery capacity). Value of 1C = Cell capacity, e.g.
