SPARE PARTS
Only use original components for the repair of defect components.
For each order of spare parts, the type and number of the motor must be given; these data are
indicated on the nameplate.
WARRANTY
Warranty matters are treated in accordance with our general conditions of sale that are valid at
the time of delivery.
MARKING OF ATEX CERTIFIED MOTORS
The motor marking contains the following information with regards to the Ex protection:
CE xxxx
Ex II 2 G
CE
CE marking
xxxx
ID of notified body responsible for surveillance
Ex
Community mark for explosion proof equipment
II
Field of application (Group II includes all fields of application except mining)
2
Category of protection: For group II: 3 (Normal), 2 (High level) or 1 (Very high level)
G
Gas hazardous locations (G)
ISSeP Notified body
Year of emission (2007, 2008, 2009, ...)
08
ATEX ATEX directive
yyy
Consecutive number of the year
X
Special conditions for safe use (if any)
Ex d
Type of protection (flameproof for use in an explosive gas atmosphere)
II
Group of equipment
B
Gas group (the classification of gases into groups is described in the standard EN600079)
Tx
Temperature classification (T3 to T6, see table below)
Gb
Equipment Protection Level
IP
Ingress protection
Temperature Class (Group II)
Maximum surface temperature
The maximum surface temperature of equipment must always be lower than the ignition
temperature of the gas or dust present in the hazardous area.
SAFETY CONSIDERATIONS
During normal use, the motor may get hot. (See above table of surface temperatures.)
Precautions may be needed to avoid the risk of burns.
The motor shaft turns at the speed that is indicated on the nameplate, and is potentially
dangerous. Precautions may be needed to ensure safe use.
In general, the relevant safety prescriptions for machines must be respected.
14/04/2016
Das Dokument darf nur vollständig und unverändert verwendet und weitergegeben werden. Es liegt in der Verantwortung des
Anwenders, die Gültigkeit dieses Dokumentes bezüglich seines Produktes sicher zu stellen.
Seite 64 von 72
ELNOR MOTORS NV
ISSeP 09 ATEX yyy X
T3
T4
200°C
135°C
INSTRUCTIONS MANUAL ATEX_2016 04 14.doc
Ex d II B Tx Gb
T5
T6
100°C
85°C
4 / 5
