12.3 Setting the stroke limiter
(optional)
Special end cap with thread
Adjusting screw
Setting the stroke limiter:
Move the actuator to the open position.
G
Screw in or unscrew the adjusting screw
G
using a suitable hexagon wrench until
the required flow rate has been reached.
Screw in the nut as far as it will go.
G
The position of the adjusting screw has
G
been secured.
L ( 0 %)
L ( 50 %)
L (100 %)
Actuator with end position setting possibility
dependent on angle of rotation (100 %)
ADA
(double
0 %
acting)
00010 not available
0020U 77
0040U 180
0080U 208
0130U 220
0200U 254
0300U 313
0500U 324
0850U 398
1200U 459
1750U 487
2100U 550
2500U 570
4000U 678
Washer
Nut
Length L [mm]
50 % 100 %
not available not available
96 115
202 224
232 255
248 277
285 317
352 392
367 410
453 508
522 585
550 613
626 701
645 721
725 772
Actuator with end position setting possibility
dependent on angle of rotation (100 %)
ASR*
(single acting)
00010
0020U
0040U
0080U
0130U
0200U
0300U
0500U
0850U
1200U
1750U
2100U
2500U
4000U
* ASR with stroke limiter: max. number of springs - S12
13

Commissioning

The equipment is subject to pressure!
Risk of severe injury or death!
®
Only work on depressurized plant.
G
Corrosive chemicals!
Risk of caustic burns!
®
Check the tightness of the
G
media connections prior to
commissioning!
Use only the appropriate
G
protective gear when
performing the tightness
check.
Protect against leakage!
Provide precautionary measures
G
against exceeding the maximum
permitted pressures caused by
pressure surges (water hammer).
Observe pertinent standards prior
to commissioning.
31 / 40
Length L [mm]
0 % 50 %
- -
194 213
220 242
250 274
300 328
334 365
393 432
436 479
500 555
599 662
647 710
751 827
796 871
998 1045
WARNING
WARNING
CAUTION
ADA / ASR
100 %
-
232
264
297
357
397
472
522
610
725
773
902
947
1092
