ADA/ ISO
□ R ∅ S 5211 ∅ L
ASR
00010 9 12.1 F03
00010 9 12.1 F04
0020U 9 12.5 F03
0020U 14 18.1 F04
0020U 14 18.1 F05
0040U 14 18.1 F04
0040U 14 18.1 F05
0080U 17 22.5 F05
0130U 17 22.5 F05
0200U 17 22.5 F07
0300U 22 28.5 F07
0500U 22 28.5 F10 102 M10x16
0850U 27 36.5 F10 102 M10x17 F12 125 M12x20
1200U 27 36.5 F10 102 M10x17 F12 125 M12x20
1200U 36 48.5 F10 102 M10x17 F14 140 M16x20
1750U 36 48.5 F14 140 M16x26
2100U 36 48.5 F14 140 M16x26
2100U 46 60.2 F16 165 M20x29
2500U 36 48.5 F14 140 M16x26
2500U 46 60.2 F16 165 M20x29
4000U 55 72.5 F16 165 M20x30 F25 254 M16x30
11

Pneumatic connection

11.1

Quality of the control medium

Use air that is free from moisture with a
minimum air quality in compliance with
ISO 8573-1 purity class 5.4.4.
Properties:
40 μm fi lter

Oil concentration: 5.0 mg/m³

Dew point:

Indoor operation: +3 °C/outdoor
operation: Correspondingly lower (purity
class 3)
Contamination
Pu-
rity
Particle Max. con-
class
size centration
1 0.1 μm 0.1 mg/m³
2 1 μm 1 mg/m³
3 5 μm 5 mg/m³
4 15 μm 8 mg/m³
5 40 μm 10 mg/m³
6 - -
11.2

Types

The following types are available:
GEMÜ ASR / Single acting
Normally closed (NC): Actuator resting
position: closed by spring force. Activation
ISO ∅
M x V
5211 L1
36 M5x8 - -
42 M5x8 - -
36 M5x8 F05 50 M6x10
42 M5x8 - -
50 M6x10 - -
42 M5x10 - -
50 M6x10 - -
50 M6x10 F07 70 M8x16
50 M6x10 F07 70 M8x16
70 M8x16 F10 102 M10x16
70 M8x16 F10 102 M10x16
- -
- -
- -
- -
- -
- -
Water Oil
Max.
Max. con-
pressure
centration
dew point
-70 °C 0.01 mg/m³
-40 °C 0.1 mg/m³
-20 °C 1.0 mg/m³
+3 °C 5.0 mg/m³
+7 °C 25.0 mg/m³
+10 °C -
of the actuator (connector 2) opens the
M1
x V1
actuator. When the actuator is vented, the
-
actuator is closed by spring force.
-
Normally open (NO):
-
Actuator resting position: opened by
-
spring force. Activation of the actuator
-
-
(connector 4) closes the actuator. When the
actuator is vented, the actuator is opened by
spring force.
- GEMÜ ADA / Double acting
Actuator resting position: no defined normal
position. The actuator is opened and
closed by activating the respective control
-
medium connectors (connector 2: open /
-
-
connector 4: close).
-
-
Type
ASR
ADA
+ = available / - = not available
(for connectors 2 / 4 see chapter 11.3)
11.3 Connecting the
control medium
Important:
Connect the control medium lines
tension-free and without any bends
or knots! Use appropriate connec-
tors according to the application.
Thread size of the control medium
connectors: G1/4
1
Remove the protection cap 1.
G
Screw the control medium line 3 into
G
control medium connector 2.
With type ADA, screw the second control
G
medium line into the control medium
connector 4.
29 / 40
Connectors
2 4
+ +
+ +
2 4
3
ADA / ASR
