Order data

Valve type
GEMÜ 532
Kit
Spare parts kit on valve side
Seat seal
PTFE
PTFE, glass fibre reinforced
Please consult GEMÜ before using other seats
Order example
Type
Nominal size
Kit (Code)
Seat seal (code)
Control function (code)
Operator size (code)
3 Components in the
SKV spare parts kit
Item Piece Name
3 1 Circlip
4 1 Gasket
5 1 Guide bush
6 1 Compression spring
7 1 Support ring
Chevron packing
8 3
(piece with actuator size 2)
9 1 Pressure ring
11 1 Hexagon nut
13 1 Piston sleeve
14 1 Seat seal
21 1 Lip ring external sealing
22 1 O-ring
24 1 O-ring (only with actuator size 2)
33 2 Chevron packing
44 1 O-ring (only with actuator size 1)
Control function
Code
532 Normally open (NO)
Code
Actuator size
SKV Actuator 0
Actuator 1
Actuator 2
Code
Actuator 3
5
Actuator 4
5G
532 25
532
25
13 / 24
Flow
piston ø 50 mm under the seat
piston ø 70 mm under the seat
piston ø 120 mm under the seat
piston dia. 50 mm over the seat
piston dia. 70 mm over the seat
SKV 5
SKV
5
Code
2
Code
0
1
2
3
4
2 1
2
1
