Standard Version - Gemü ADA 00010 Betriebsanleitung

Standard version

Standard version
ADA 00010
4
10
4
Item Description
1 Housing
2 Piston
3 Shaft
4 End caps
5 Thrust washer
6 Sliding piston
7 Bearing
Spring configuration:
● = with spring ○ = without spring
ASR 0020U
S04
ASR 0040U - 4000U
S04
ASR 0040U - 0080U
S10
* S12 - maximum spring confi guration of single acting
actuators with stroke limiter
12
3
14
13
14
Material / Specification
Aluminium
Aluminium
C-steel, nickel coated
Aluminium, epoxy coated
Polyamide PA 6.6
Polyamide PA 6.6, 30 % glass
reinforced
Polyamide PA 6.6
S06
S06
S12*
11
5
7
8
10
7
1
Item Description
Setting of end
8
positions
9 Spring sets
10 Adjusting screws
11 Springs
12 Position indicator
13 Centring ring
14 O-rings
S08
S08
S14
37 / 40
14
9
2
6
Material / Specification
ASTM A 105
Polyamide PA 6.6
Stainless steel
DIN 2076 D-5.6
Polypropylene
Cast steel, nickel-plated
NBR
ADA / ASR
