19

Troubleshooting / Fault clearance

Fault Possible cause
Operating pressure too high
Control pressure too low
Control medium not connected
The actuator design is not suitable
Actuator does
for the operating conditions
not open /
close or does
End positions incorrectly adjusted
not open /
close fully
Stroke limiter (optional) incorrectly
adjusted
Actuator faulty
Contaminated control medium
Foreign matter in the shut-off valve
Actuator damaged
Actuator
leaking at
Valve body damaged
the mounting
flange
Unions loose
Incorrect installation
20

Exploded drawing and spare parts

Multifunction indicator SP.ADA/ASR ...
Quantity Name
Multifunction indicator with optical position indicator,
1 piece
mounting sleeve and scale ring
For procedure, see chapter 14.3, "Replacing spare parts in the multifunction indicator".
Multifunction indicator SP.ADA/ASR ... U
Quantity Name
Multifunction indicator with optical position indicator,
1 piece
metal insert, mounting sleeve and scale ring
For procedure, see chapter 14.3, "Replacing spare parts in the multifunction indicator".
ADA / ASR
Fault clearance
Operate the shut-off valve with the operating pressure
specifi ed in the datasheet
Operate the actuator with the control pressure specified in
the datasheet (6 - 8 bar)
Connect control medium
Use an actuator that is designed for the operating
conditions
Correctly adjust the end positions (see chapter 12.2
"Adjusting the end positions")
Correctly adjust the stroke limiter (optional) (see chapter
12.3 "Setting the stroke limiter (optional)")
Replace actuator (see chapter 14.2 "Replacing the
actuator")
Disassemble and clean the actuator, install a filter upstream
Disassemble and clean the shut-off valve
Check actuator for damage, if necessary replace actuator
(see chapter 14.2 "Replacing the actuator")
Check the valve body for potential damage and replace the
valve body if necessary
Tighten unions
Check the installation of the actuator on the valve body
EDP number
}
88393278 (ADA / ASR 00010)
EDP number
}
88428188 (ADA / ASR 0020U - 0850U)
88428190 (ADA / ASR 1200U - 4000U)
36 / 40
