3.4.2 Connecting the Scale
Connecting the Scale
t
Laying the USB Cable
t
Connection to the Power Supply
t
Insert the USB cable into a USB socket of a PC or laptop.
Connecting an AC adapter
(option)
t
t

3.5 Anti-theft Locking Device

t

3.6 Leveling

Leveling the HD Model
Leveling the scale compensates for slant or
unevenness at the place of installation.
The scale must be perfectly horizontal to ensure
consistent, reproducible weighing results.
The scale needs to be re-leveled and then
adjusted each time its setup location is changed.
t
12*
9*
− Air bubble at "12 o'clock":
6*
− Air bubble at "3 o'clock":
* Clock
− Air bubble at "6 o'clock": turn
− Air bubble at "9 o'clock": turn
6 Installation Instructions EVO1S1 | SPO1S1
Insert the USB cable into the
USB socket on the back of the
display.
Lay the USB cable through the
cable holders on the back of the
scale.
Insert the USB cable into the
YPS06-USB AC adapter.
Plug the AC adapter into the
wall outlet (supply voltage).
If required, secure the scale at
the back.
Turn the two leveling feet as
shown in the illustration until
the air bubble is centered within
the circle of the level indicator.
turn the two feet clockwise.
turn the left foot clockwise and
the right foot counterclockwise.
the two feet counterclockwise.
the left foot counterclockwise
and the right foot clockwise.

3.7 Warm-up Time

0
To ensure accurate results are
delivered, the scale must warm up
for at least 30 minutes after initial
connection to the power supply.
Only after this time will the scale
have reached the required
operating temperature.
30

4. Care and Maintenance

4.1 Cleaning

Electrical hazard from voltage or current!
Disconnect the AC adapter from the power
supply. If necessary, disconnect the data cable if
connected to the scale. Never open the scale or
the AC adapter.
The parts contained in these cannot be cleaned,
repaired or replaced by the operator.
− Make sure that no liquid or dust gets into the scale or the
AC adapter.
− Only use soft brushes and cloths for cleaning.
− Never use cleaning agents that contain solvents or
abrasive ingredients (e.g. scouring cream, steel wool).
This can ultimately damage the equipment.
Do not clean the following parts with acetone or
aggressive cleaning agents:
mains socket, data interface, labels, and all other
plastic parts.
Cleaning the Control Panel
t
Turn off the device before cleaning the user interface,
since touching the screen could trigger unwanted inputs.
Cleaning the Scale Housing
t
Clean the device using a mild cleaning agent.
t
Use a soft cloth to dry the device.

4.2 Maintenance

Electrical hazard from voltage or current!
Repair work on the AC adapter (optional)
must only be carried out by trained service
technicians. Contact Sartorius Service or a
Sartorius dealer for proper repairs.
To ensure the continued accuracy of your scale, we
recommend scheduling regular servicing at least once a year.
Sartorius Service offers different service contracts with
maintenance intervals that are tailored to your needs.
A calibration certificate should always be issued as part of
every maintenance session. Safety inspections of the AC
adapter and its connections must be performed at appropriate
intervals by a qualified electrician (e.g., every 2 years).
