List of replacement parts PILOT WA 81
Item Description
1 Distributor cone
2 Air sleeve
3 O - ring
4 Distance sleeeve
5 Material nozzle
6 O - ring
7 Head piece
8 Air cap nut
9 Air tube
10 Material tube
11 Packing screw
12 Needle seal complete
13 Housing, complete
14 Lip seal
15 Material needle
16 Piston
17 O - ring
18 Needle nut
19 Piston spring
20 Spring bushing
21 Hexagonal socket screw
22 Fastening bolt
* Please indicate the required sizes when placing an order for replacement parts.
We recommend that bold-face replacement parts (i.e. wear parts) are hold on
stock.
Nozzle sizes optional:
• 1,0 • 1,5 mm ø
PILOT WA 81
V 20 381
Qty. Art.-No.
1
V 30 146 01 003
1 V 30 146 03 003
1 V 09 103 33 001
1
V 30 146 02 003
1 V 30 146 05 . . 3*
1 V 09 103 20 001
1 V 30 146 04 003
1 V 20 380 13 003
1
V 20 380 10 003
1 V 20 380 11 003
1
V 20 305 04 003
1 V 20 305 13 000
1 V 20 306 01 003
1
V 09 220 26 000
1 V 20 381 12 . . 3*
1
V 20 305 03 004
1 V 09 102 21 001
1 V 20 305 07 003
1 V 20 305 12 005
1 V 20 305 02 003
2
V 20 305 08 003
1 V 20 305 14 003
22
1

General

1.1

Identification of Model Versions

Models: Automatic Spray Guns PILOT WA 81
Type: Pipe Crawler
Manufacturer: WALTHER Spritz-und Lackiersysteme GmbH
Kärntner Str. 18-30
D-42327 Wuppertal
Tel.: 00 49 202 / 787-0
Fax: 00 49 202 / 787-2217
www.walther-pilot.de • Email: info@walther-pilot.de
1.2

Normal Use

The automatic spray gun PILOT WA 81 must be used only for processing sprayable
materials in tubes and cavities and can be used for coating tubes with an inner dia-
meter of up to approx. 500 mm. All material conduction parts are made of stainless
steel so as to permit handling of hydrous and/ or agressive media such as:
• lacquers and paints
• grease, oil and anti-corrosion agents
• adhesives
• ceramic glazes
• stains
•
If you intend to spray materials that are not listed here, please contact WALTHER
Spritz- und Lackiersysteme GmbH, Wuppertal.
The sprayable materials must be sprayed only on workpieces or objects.
The temperature of the material to be sprayed must not exceed 80°C.
The model PILOT WA 81 is not a hand-held spray gun and must therefore be
mounted in a suitable bracket.
The term normal use also implies that any and all safety warnings, operational
handling details, etc., as stated in these operating instructions, must be carefully
read, understood and duly complied with.
This equipment complies with the explosion protection requirements of Directive
94 / 9 / EC (ATEX) for the explosion group, equipment category and temperature
class indicated on the type plate.
When using the equipment, the requirements specified in these Operating
Instructions must be observed at all times.
The technical data indicated on the equipment rating plates and the specifications
in the chapter „Technical Data" must be complied with at all times and must not be
exceeded. An overloading of the equipment must be ruled out.
The equipment may be used in potentially explosive atmospheres only with the
authorisation of the relevant supervisory authority.
The relevant supervisory authority or the operator of the equipment are
responsible for determining the explosion hazard (zone classification).
