◄ Air caps optional:
Nozzle Size
Wide jet air cap
0,8 - 1,4 mm ø
Round jet air cap
0,8 - 1,4 mm ø
Nozzle / needle sets
Material nozzle (Pos. 3.1) and Material Needle compl. (Pos. 3.2)
Nozzle Size
PILOT 2K Bonding
Sealing and spring set A-Komponente
Valve spring (Pos. 7), Spring bushing compl. (Pos. 8), Needle spring (Pos. 9), Needle seal
(Pos. 17) und Pressure spring (Pos. 19)
PILOT 2K Bonding
Repair set B-Komponente
Material nozzle (Pos. 24.1), O-Ring (Pos. 24.2), needle seal (Pos. 24.4) material needle com-
pl. (Pos. 24.7), spring (Pos. 24.8) und O-Ring (Pos. 24.11)
PILOT 2K Bonding
Size Article-No.
Bore for Component B (Activator)
0,3 mm ø V 11 820 03 003
0,4 mm ø V 11 820 04 003
0,5 mm ø V 11 820 05 003
0,3 mm ø V 11 821 03 003
0,4 mm ø V 11 821 04 003
0,5 mm ø V 11 821 05 003
Article-No.
0,8 2410681
1,0 2411498
1,2 2411499
1,4 2411500
Article-No.
2411502
Article-No.
2411503
22
1

General

1.1

Model identification

Model: Two-component hand spray gun
Type: PILOT 2K Bonding Wide jet
PILOT 2K Bonding Round jet
Manufacturer:
WALTHER Spritz- und Lackiersysteme GmbH
Kärntner Str. 18-30
D-42327 Wuppertal
Tel.: +202 / 787-0
Fax: +202 / 787-2217
www.walther-pilot.de • Email: info@walther-pilot.de
1.2

Intended use

The manual spray gun PILOT 2K Bonding is used exclusively to process sprayable
water-soluble non-flammable two-component media. Because all material-carrying
parts are manufactured from stainless steel the model PILOT 2K Bonding is suited
for the application of water-soluble two-component adhesives in the upholstery and
foamed plastic industry.
Please contact WALTHER Spritz- und Lackiersysteme GmbH, Wuppertal if other
materials shall be sprayed.
The sprayable materials may only be applied to work pieces or objects.
The temperature of the sprayed material must generally not exceed 43 °C.
Intended use also includes the reading and understanding of, as well as compliance
with all information and data in the operating instructions.
The information on the device signs or the details in the chapter on technical data
must be absolutely complied with and may not be exceeded. Overloading the device
must be ruled out.
If any particularities are noted during operation, the device must be shut down imme-
diately and WALTHER Spritz- und Lackiersysteme shall be contacted.
1.3

Unintended use

The spray gun must not be used for purposes other than those set forth in section
Intended use.
Any other use is considered inappropriate.
Inappropriate use includes, for example:
• spraying materials on persons and animals
• spraying liquid nitrogen.
• spraying of flammable materials
V 11 820 0x xx3
V 11 821 0x xx3
