Clean the spray gun
•
prior to each change of the spraying medium
•
at least once a week
•
as often as may be required by the spraying medium handled and the resulted
degree of fouling.
1.
Dismantle the gun as described in section 5.5 Retooling the Spray Gun.
2.
Clean the nozzle with a brush dipped in the recommended cleaning solution.
3.
Clean the gun body and all remaining parts with a soft cloth and the recom-
mended cleaning solution.
4.
Apply a thin layer of grease to the following parts:
•
Material needle
•
Piston spring
•
O-ring of the piston
Use non-acidic, non-resinogenic grease and a brush. The spray gun is then reas-
sembled in reverse order.
7
Repairs
Warning
Prior to any repairs: Make sure that the spray gun is in unpressurized condition, i.e.
all air and material inputs must be shut off - if not, imminent risk of injury.
Note
Please use the drawing (page 6) of these operating instructions to perform the follo-
wing procedures.
7.1
Replacement of Material Nozzles and -Needles
Dismantle the spray gun in accordance with Chapter 5.5 Changing of Material
Nozzle and Needle, if the following components have to be replaced:
•
Material Nozzle
•
Piston Spring*
•
Material Needle*
•
Piston O-Ring*
Note
Parts marked with * must be lubricated with non-acidic, non-resinogenic grease
prior to installation.
7.2
Changing the Needle Seal
1.
Dismantle the material nozzle and needle as outlined in section 5.5.
2.
Unscrew the head piece (item 7) from the air tube (item 9).
3.
Unscrew the air head nut (item 8) from the housing (item 13) and remove the
air tube (item 9).
4.
Unscrew the material tube (item 10).
30
5.
Unscrew the packing screw (item 11) from the housing (item 13).
6.
Pull out the needle seal (item 12) from the housing. You may need to use a thin
wire with the end bent to a hook.
Installation takes place in reverse order.
Note
Never reinstall a used needle seal (Item 12) as otherwise the functional sealing
reliability of the spray gun will suffer.
The ware parts are maked in bold face in the replacement parts list.
8
Troubleshooting and Corrective Action
Warning
Prior to any servicing and repair work: Make sure that the spray gun is in unpressu-
rized condition, i.e. all air and material inputs must be shut off - if not, imminent risk
of injury.
Fault
Cause
Material control nozzle
(Item 15) or needle
(Item 5) fouled
Gun is dripping
Material control nozzle or
needle damaged
Control air pressure too
Gun fails to open
low
Atomising air is entering
the material container via
the material channel
Material bubbling in
material container
Material nozzle (Item 5) or
air tube (Item 9) not pro-
perly tightened.
Spray jet pulsating
Level in material tank too
or unsteady
low
Distributor cone damaged
Spray fan one-sided
or dirty
Material leaks from
Needle seal packing
leakage boring
(Item 12) leaks
31
Remedy
see 5.5 Removing Material
Nozzle or Needle and
cleaning
see 5.5 Replacing Material
Control Nozzle or Needle
Increaese control air pressu-
re to at least 4.5 bar
Clean the parts, tighten or
replace
Top-up material level (see
operating instructions of
plant systems manufacturer)
Remove and clean
exchange
