Overview of the device and scope of supply

9
8
7
6
17
16
15
14
1 Release button for the dust bag con-
tainer
2 Suction hose connection
3 Button for retracting the mains cable
4 Release button for the fi lter compartment
5 Storage bracket
6 Filter compartment with exhaust fi lter
7 On/off switch
8 Suction force dial
9 Handle
10 Suction hose
11 Telescopic extension tube
12 Storage hook
13 Crevice nozzle
14 Floor nozzle
15 Brush and upholstery nozzle
16 Bracket for nozzles
17 Handle with exhaust air valve
