6.1 How it works

The linear unit is used for linear processing and positioning. A toothed belt drive moves the slot
into its position. This motion can be effected manually with a handwheel or by an electric drive.
Depending on the version, the slides are guided without any play on rail sections or steel guide
shafts with rollers.

6.2 Designs/Guidance concept

This linear unit is available in the designs and guidance versions given here.
•
After receiving this linear unit, check the device for possible damage and missing components.
•
Notify RK Rose+Krieger GmbH of any faults found immediately.
The linear unit is delivered ready for operation, but without a controller and without accessories.

6.2.1 Designs

RK MultiLine II Z
Design with ball rail
RK MultiLine II Z
Design with ball rail, without drive

6.3 Guidance concept

After receiving this linear unit, check the device for possible
damage and missing components.
If you find any faults, inform RK Rose+Krieger GmbH of the-
se immediately. The linear unit is delivered ready for opera-
tion, but without a control system and without accessories.
