8.3 Exploded view

Take the parts lists, RK's standard component naming and their installation position in the linear
shaft.
Technical variations are possible and depend on the size and version of the linear shaft.
7
8
9
1 Toothed belt drive
2 Toothed belt
3 Guidance section
4 Toothed belt tensioning kit
5 Toothed belt steering
1 2
8. Spare parts lists/accessories
3
6 Bearing cover
7 Guidance slots
8 Cover
9 ball rail guide
5
6
4
55
