Balanced Body Reformer Trapeze Combination Handbuch Seite 9

OPTION: INSTALLING THE TWIN MATS
1. Pull pins and completely lower risers.
2. Remove shoulder rests from the carriage.
3. Detach all springs from springbar and move the carriage
toward the head end of the frame.
4. Rotate the footbar support up to the padded section of the
footbar and then lay the footbar down onto the frame rails. It
should now be inside the frame and lower than the top of
the frame.
5. Vinyl flaps are installed inside one mat for shipping purposes.
Detach, rotate, and reinstall flaps so they hang down from the
edge of the mat aligned with eye bolts.
6. Place the mat with vinyl flaps at the head-end of the Reformer
with flaps facing the PTB. The Vinyl flaps should hang over
the head-end of frame. They are designed to protect the mat
conversion when using the PTB with a bottom spring.
7. Place the remaining mat on the foot-end of the Reformer.
Make sure the end of the mat with the feet further from the
edge is installed over the standing platform.
WEEKLY MAINTENANCE
8. Inspect springs for separations, and replace if needed. Inspect
snaps on springs and make sure the retractors operate
smoothly. Replace them if worn or do not operate freely. Make
sure that there are no indentations on the inside of the hooks.
9. Inspect all nuts, eyebolts and set screws for tightness.
Tighten or replace if necessary.
10. Check to see if quick release pins on the PTB operate
correctly. Does the ball at the end of the pin protrude? Does
the ball retract when the button is pressed? If not, replace
the pin.
WARNING: This machine is potentially dangerous, and Balanced
Body Inc. assumes no liability towards use or misuse. If you are
not fully aware of the safety issues and use of this machine, do
not use it.
QUESTIONS?
Call Balanced Body Technical Support at 1-800-PILATES or
+1-916-388-2838.
7
