Balanced Body Reformer Trapeze Combination Handbuch Seite 6

How to Assemble The Balanced Body®
Reformer Trapeze Combination™
REFORMER PARTS LIST
Description
Cotton Footstrap
Red Reformer Spring
Blue Reformer Spring
Green Reformer Spring
Ropes w/Snaps (pair)
Single Loop, Cotton (pair)
Neoprene Handles (pair)
Standard Sitting Box
Mat Conversion
Extension Stopper
Retractrable Risers (pair)
Shoulder Rest (pair)
4
Part Number Qty.
210-030 1
SPR9070 3
SPR9071 1
SPR9293 1
210-026 1
101-005 1
101-016 1
721-002 1
707-068 1
200-211 1
950-184 1
950-042 1
CANOPY/TRAPEZE PARTS LIST
Description
Ankle Velcro (pair)
Long Cotton Web, Black (pair)
Thigh Velcro (pair)
Wool Fuzzy (pair)
Belly Strap - Black
T-Pin
Push Thru Bar (PTB)
Red Trapeze Spring
Yellow Trapeze Spring
Blue Trapeze Spring
Long Yellow Spring
Long Purple Spring
Safety Strap
Push Thru Connector Bar
Trapeze Bar Assembly
Vertical Tubes with PTB installed
Vertical Tubes with Slider Bar installed N/A
Canopy Top Assembly with Slider Bar
Cotter Pin
TOOLS
3/16" Allen Wrench
Part Number Qty.
101-001 1
101-026 1
101-020 1
101-022 1
210-034 1
GEN9892 2
707-098 1
SPR9001 2
SPR9002 2
SPR9004 2
SPR9006 2
SPR9461 2
210-021 1
TRP0020 1
950-059 1
N/A 1
1
N/A 1
216-000 4
GEN9280 1
