English
Index / page
1. GROUP I (about 9 to 18 kg Y)
HEYNER ® MultiProtect ERGO SP as a child car seat
1.1. Using HEYNER
HEYNER ® MultiProtect ERGO SP to your child's size
1.2. Adjusting HEYNER
HEYNER ® MultiProtect ERGO SP into your car
1.3. Installing HEYNER
HEYNER ® MultiProtect ERGO SP
1.4. Securing the child into HEYNER
2. GROUP II+III (about 15 to 36 kg)
HEYNER ® MultiProtect ERGO SP without harness belts
2.1. Using HEYNER
2.2. Adjusting the headrest
3. Care instructions
4. Important notices
5. Some final hints
A Headrest J1 for children up to 1.5 years
B Backrest (children about 9 - 12 kg)
C Booster K Belt anchorage
D Harness belt L Fixation lugs for three-point-vehicle-belt
D1 Shoulder belt M Belt clip
D2 Waist belt N Diagonal belt of the three-point-vehicle-belt
D3 Harness central belt O Lap belt of the three-point-vehicle-belt
D4 Buckle belt P Buckle latch of the three-point-vehicle-belt
E Buckle latches Q Belt buckle of the three-point-vehicle-belt
F Belt buckle R Connecting hooks
G Belt hook S Connecting holes
H Belt adjuster T Backrest cover velcro
I Belt end element U Booster cover velcro
J Shoulder belt slots V Backrest cover button
J3 for children up to 3 years W Shoulder pad connector
(children about 14 - 18 kg) X Belt anchorage of waist belt
J2 for children up to 2 years Y Belt anchorage of buckle belt
(children about 12 - 14 kg) Z Head rest de-block lever
www.heyner-germany.de
11
1. GROUP I (about 9 to 18 kg Y)
S. 12
S. 12
HEYNER ® MultiProtect ERGO SP as a child car seat
1.1. Using HEYNER
S. 12
S. 14
HEYNER ® MultiProtect ERGO SP car seat for your child. We thank you
You have purchased HEYNER
S. 16
for your trust. Please note, that the optimum safety characteristics can only be achieved, if the
S. 17
seat is used properly according to instructions. Therefore we ask you to ensure the correct
S. 17
installation of the seat in your vehicle by reading the operating instructions carefully. Please
S. 18
keep instructions always with the seat for further information. Only to be assembled by adults!
S. 19
S. 19
Connecting the backrest to the booster seat (fig.26) (just if non-assembled)
S. 20
If backrest (B) and booster (C) are delivered in a non-assembled way, please follow these
instructions to connect both together before using it for children in group I, II & III:
Lay down the booster on the floor and the backrest flat right behind. Then thread the connecting
hooks (R) on the bottom of the backrest into the fitting holes (S) on the back of the booster (C)
with a firm downwards motion. Now bring the backrest slowly upright 90° to the booster. The
connecting hooks should now slip into the fitting holes with an audible sound. As a result the
backrest should be well fixed to the booster in the upright position. It must not slip away now.
Otherwise you may not have fixed it very well and using it would be dangerous. In this case
please repeat the first steps of this part of the instruction.
HEYNER ® MultiProtect ERGO SP to your child's size
1.2. Adjusting HEYNER
1.2.1. Preparation (fig.1a-c)
HEYNER ® MultiProtect ERGO SP is equipped with a head cushion and a reduction cushion, to
HEYNER
assure special protection of small children starting from 9kg weight. In case the head rest (A)
www.heyner-germany.de
English
GB
HEYNER
HEYNER
