Technische Daten
PSD NOISE MEASUREMENT
Test type
Vertical scale
Horizontal scale
Noise filters
DSL IMPULSE NOISE MEASUREMENT
Threshold
Counter
Test duration
Histogram plot interval
Uncertainty (accuracy) (dB)
SWEPT LONGITUDINAL BALANCE TEST
Frequency accuracy (ppm)
Uncertainty (accuracy)(dB)
Vertical scale (dB)
Horizontal scale
DMM (DIGITAL MULTIMETER)
Measurement
DC voltage
AC voltage
Resistance
Capacitance
DC current
AC current
SPECTRAL DETECTIVE
Allows the AXS-200/625 to bridge (high-impedance) onto a live circuit to display a plot of transmitted levels and spectrum (PSD). The Spectral Detective test can be
referenced to any user-selected impedance. The impedance reference setting is required to display proper readings in dBm/Hz or dBm.
Test type
Bridging impedance (kΩ)
Vertical scale
Horizontal scale
Noise filters
STRESS/LEAKAGE (ISOLATION RESISTANCE)
Source
Range (MΩ)
Resolution
Uncertainty (accuracy)
Soak timer (s)
RFL
Test type
Fault detection (MΩ)
Resolution
Loop resistance (kΩ )
Multiple cable sections
Fault location
Uncertainty (accuracy) (Ω )
180
Continuous or peak-hold
–10 dBm/Hz to –145 dBm/Hz or +20 dBm to –110 dBm
4.3125 kHz to 17 MHz, in 4.3125 kHz steps or 8.625 kHz to 30 MHz, in 8.625 kHz steps
None or E, F, G, VDSL2-8, VDSL2-12, VDSL2-17 and VDSL2-30
–50 dBm (40 dBrn) to 0 dBm (90 dBrn) in 1 dB steps
Maximum 65 000
1, 5, 10, 15 and 60 min, 24 h or continuous (up to 360 h)
1, 5, 10, 15 or 60 min
±2
±50
±2.0
0 to 80.0 up to 2.2 MHz
0 to 60.0 up to 30 MHz
ADSL/2+: 26 kHz to 2.2 MHz
SHDSL: 26 kHz to 1 MHz
VDSL/VDSL2-12: 26 kHz to 12 MHz
VDSL2-17: 26 kHz to 17.66 MHz
VDSL2-30: 26 kHz to 30 MHz
Range
0 to 200 V
0 to 140 Vrms
0 to 999 MΩ
0 to 999 Ω
1 kΩ to 99 MΩ
100 MΩ to 999 MΩ
Distance up to 30 000 m (100 000 ft)
1 nF to 10 µ F
Distance up to 30 000 m (100 000 ft)
0 to 110 mA
0 to 77 mA
Continuous or peak-hold
15 kΩ
–10 to –145 dBm/Hz or +20 to –110 dBm
4.3125 kHz to 17 MHz, in 4.3125 kHz steps or 8.625 kHz to 30 MHz, in 8.625 kHz steps
None or E, F, G, VDSL2-8, VDSL2-12, VDSL2-17 and VDSL2-30
100 VDC, current safely limited to < 1.0 mA
0 to 999 auto-ranging
3 significant digits
0 to 999 Ω , the better of ±1 % or ±5 Ω
1 kΩ to 99 MΩ , the better of ±1 % or ±1 digit
100 MΩ to 999 MΩ , the better of ±5 % or ±1 digit
1 to 99
Single pair and separate good pair
0 to 20
3 digits
7 maximum
Five (includes gauge and temperature setting)
*Total resistance, near-end to fault resistance, fault to strap resistance (four significant digits)
*Total length, distance to fault, distance from fault to strap (3 ft/1 m resolution)
The better of 0.2 Ω or ±2 %
Resolution
Accuracy
1 V
the better of ±2 % or ±1 V
1 V
the better of ±2 % or ±1 V
3 digits
the better of ±2 % or ±5 Ω
the better of ±2 % or ±1 digit
the better of ±5 % or ±1 digit
3 digits
the better of ±2 % or ±1 digit
1 mA
the better of ±2 % or ±1 digit
1 mA
the better of ±2 % or ±1 digit
