Settings
1.
*"Weekly Program"
■
*"All Days [X]": The appliance
mows every day at the set times. If "All
Days [ ]" is shown, the appliance only
mows on the set days of the week.
■
*"Monday [X]"...*"Sunday
[X]": The appliance mows for the set
time periods on the set day of the week.
If "Monday [ ]" is shown, for example,
the appliance does not mow on the re-
spective day.
■
"Change"
day [X] or deactivate it [ ], and set the
time periods, type of mowing and the
start points.
2. Make the settings for every day or the re-
spective day:
■
For example, "*[M] 07:00-10:00
[?]": Normal mowing [M] from 07:00 –
10:00 am with automatically changing
start point 0 – 9 [?].
■
For example, "*[R] 16:00-18:00
[1]": The appliance starts with edge
mowing [R] at 4 pm and moves along
the entire boundary cable. The area
mowing then begins at start point 1 [1].
At 6 pm or as soon as the rechargeable
battery is discharged, the appliance
moves back to the base station.
■
"Change"
setting.
■
"Continue"
setting and continue to the next setting.
3. "Save" : Save all changed settings of
the menu item.
7.5

Edge mowing with a manual start

For a manual start, the setting can be made here
that the appliance begins with edge mowing.
Carrying out the edge mowing at the pro-
grammed mowing time periods: see chapter 7.4.3
"Setting the mowing times", page 48.
1.
*"Margin mowing"
2.
*"at manual start"
457293_a
: Activate the respective
: Change the selected
: Confirm the changes
7.6

Setting the secondary area mowing

1.
*"Sub zone mowing"
2. Setting the mowing time periods:
■
"inactive"
area mowing is switched off.
■
"active"
mows until the rechargeable battery is
flat.
■
"Mowing time in min"
The appliance mows the secondary area
for the set time period. The following
mowing time periods can be set:
30/60/90/120/until rechargeable battery
flat.
7.7

Setting the display contrast

If the display is difficult to read, e.g. in sunlight,
the display can be improved by changing the dis-
play contrast.
1.
*"Display contrast"
2. Increase/decrease display contrast.
7.8

Setting lock

If the setting lock is deactivated, the PIN must
only be entered when acknowledging safety-rel-
evant faults.
1.
*"Safety settings"
2. Activating/deactivating the setting lock:
■
"Activate"
Activate the setting lock.
■
"Deactivate"
Deactivate the setting lock.
7.9

Recalibrating

If the position or length of the boundary cable has
been changed or the appliance no longer finds
the boundary cable, recalibration is necessary.
1. "Reset calibration"
2. "Reset loop calibration data?"
3. Carrying out a calibration movement: see
chapter 5.4 "Carrying out an automatic calib-
ration movement", page 46.
: Secondary
: The appliance
:
:
:
49
