GB
7.3

Setting the rain sensor

NOTE
Mowing when the grass is dry reduces
soiling.
By activating the rain sensor and setting
a delay time, it is possible to prevent the
appliance mowing when the grass is wet.
If the rain sensor is activated, the appliance
moves back into the base station when the rain
begins. It remains there until the rain sensor has
dried. Then it waits for the time period that is set
as the delay before it continues mowing.
1.
*"Rain sensor"
2. Activating/deactivating the rain sensor:
■
"Activate"
Activate the rain sensor.
■
"Deactivate"
Deactivate the rain sensor.
3. Setting the delay of the rain sensor:
■
*"After rain delay"
■
"xx hours xx minutes"
Select the required value for the hour/
minute in sequence with
firm each time with
7.4

Setting the mowing program

7.4.1 Setting the mowing program – General
1. Call up the main menu.
2.
*"Programs"
3. Select the menu item.
4. Make the settings.
Note: The menu items are described in the
following sections.
7.4.2

Setting the start points

Teaching-in start points
1. Place the appliance in the base station.
2. Switch on the appliance.
3. Call up the main menu.
4.
*"Programs"
5.
*"Entry Point"
6.
*"Interactive teach"
48
:
:
and con-
.
7.
*" Start interactive entry
point teaching "
■
" Start "
along the boundary cable.
■
" Set "
reached the required start point. The start
point is stored.
8. " Set entry point 1 "
point has been specified during the teaching-
in movement. If no start point has been spe-
cified here, the start points are automatically
specified.
9. " Entry point x: XXm " if the last start
point has been reached.
Manually specifying start points (01)
The first start point (01/X0) is pre-set and is 1 m
to right of the base station. Up to 9 other start
points (X1 to X9) can be programmed behind this
point. When specifying the start points, heed the
following:
■
Do not set start points too far from the base
station or too close to one another (02/f).
■
Only use as many start points as necessary.
1.
*"Entry Point"
2.
*"Point X1 at [020um]"
Select one digit in sequence with
and confirm each time with
3. *"Point X2 at [075 m] "
Select one digit in sequence with
confirm each time with
4. If necessary, specify further start points.
5. Return to the main menu.
7.4.3

Setting the mowing times

NOTE
There must be at least 30 min. between
programming the mowing times and the
mowing start. If not, the appliance only
starts at the next programmed mowing
time.
In the "Weekly Program" menu item, the days
of the week and time periods when the appliance
should mow are set. Adapt these settings to the
size of your garden if necessary. If unmown
areas are still visible after approx. one week, in-
crease the mowing periods.
Settings
.
. The appliance moves
when the appliance has
if no start
.
.
Robolinho 3100
to
and
