GB

5 START-UP

This chapter describes the activities and settings
that are necessary to put the automatic lawn
mower into operation for the first time after as-
sembly. For all further settings, refer to see
chapter 7 "Settings", page 47.
5.1

Charging the rechargeable battery (09)

The integrated battery is partially charged on de-
livery. During normal operation, the battery of the
appliance is regularly charged automatically.
NOTE
Fully charge the rechargeable battery be-
fore using it for the first time. The re-
chargeable battery can be charged in any
charge status. Interrupting charging does
not damage the rechargeable battery.
The rechargeable battery can only be
charged after the appliance has been
switched on.
1. Place the appliance (09/1) in the base station
(09/3) so the contact surfaces of the appli-
ance touch the charging contacts of the base
station.
2. Switch on the appliance.
3. The display on the appliance shows: "Bat-
tery is being recharged". If not: see
chapter 13 "Help in case of malfunction",
page 54.
5.2

Making the basic settings

1. Fold up the cover flap of the control panel.
2. Switch on the appliance. The firmware,
code number and type are displayed.
3. In the menu for language selection, select:

"English"

4. In the "Login" > "Enter PIN" menu, enter
the pre-set PIN 0000. To do so, select the di-
git with and confirm each time with
. After entering the PIN, access is en-
abled.
5. In the "Change PIN" menu:
■
Under "Enter new PIN", enter a self-
selected new four-digit PIN. To do so, se-
lect one digit in sequence with
confirm each time with
46
.
and
.
■
Under "Reenter new PIN", enter the
new PIN again. If both entries are
identical, the following is displayed: "PIN
changed".
6. In the "Enter date" menu, set the current
date (format: DD.MM.20YY). To do so, select
one digit in sequence with
each time with
7. In the "Enter time" > "HH:MM" menu, set
the current time (format: HH:MM). To do so,
select one digit in sequence with
confirm each time with
The basic settings have been completed. The
"Not calibrated Press Start key" status
is displayed.
5.3

Setting the cutting height

The cutting height can be manually adjusted to
between 30 – 60 mm with a step width of 5 mm.
1. Open the cover (12/1).
2. Fold out the lever (12/2) and turn clockwise
until the broad side points towards the open
lock (12/4).
3. Setting the cutting height:
■
Pull the lever upwards in stages. The cut-
ting height (i.e. grass height) is in-
creased.
■
Press the lever downwards in stages.
The cutting height (i.e. grass height) is
reduced.
4. Turn the lever anti-clockwise until the broad
side points towards the closed lock (12/3).
5. Fold down the lever.
6. Close the cover.
5.4 Carrying out an automatic calibration
movement
Place the appliance at the starting position
(10)
1. Place the appliance at the starting position in-
side the mowing area:
■
At least 1 m left and 1 m in front of the
base station
■
Aligned with the front side to the bound-
ary cable
Start-up
and confirm
.
and
.
Robolinho 3100
