Kill-function
Via the Kill-function, you can set only the desired channels to 100 % in a running chaser. All other channels
remain off, the chaser keeps running internally.
Call up the desired chaser. Press the Rec/Exit-button and the Kill-LED shines. Press the desired Flash-
button(s) of the desired channel(s).
MIDI In-mode
Press and hold the Record-button.
Press the Flash-button 1 in Preset A three times.
Release the Record-button.
The display shows "CH-1" and the Scene Setter is in MIDI In-mode.
Select the desired MIDI-channel by pressing the respective Flash-button in Preset A.
Press and hold the Record-button.
Press the Rec Exit-button.
The MIDI-channel was memorized and you are in the normal mode again.

MIDI Out-mode

Press and hold the Record-button.
Press the Flash-button 2 in Preset A three times.
Release the Record-button.
The display shows "CH-0" and the Scene Setter is in MIDI Out-mode.
Select the desired MIDI-channel by pressing the respective Flash-button in Preset A.
Press and hold the Record-button.
Press the Rec Exit-button.
The MIDI-channel was memorized and you are in the normal mode again.
Sys-Ex Dump
With this function, you can transmit the memory content between two Scene Setters or to another Midi Sys-
Ex compatible Sequenzer or computer.
Please note: a received Sys-Ex Dump can delete all settings of a device. If you do not wish that a device
accidentally receives Sys-Ex data, switch it off or adjust another Midi-channel.
Connect the Midi Out-socket of the sending device with the Midi In-socket of the receiving one.
When sending or receiving Sys-Ex dump, the device ID is 55H.
The different functions of the individual notes are as follows:
Note Velocity
22-69 Program Master
70-93 Channel dimmer
94
95
96
97
98
99
100
101
102
Receive a Sys-Ex dump
Press and hold the Record-button.
Function
Turn on/off program 1-48
Turn on/off channel 1-24
Full On
Dark
Hold
Turn Audio chase on/off
Chaser/Scenes
Double Preset Mode
Single Preset Mode
Change step
Blackout
