The chaser will be called up.
Press the Mode Select-button, until the 1-48 Single/Preset Park-LED is lit.
Push the Master A-fader to maximum.
Push channel-faders to the desired setting.
Press the Record-button.
Push all channel-faders to minimum.
Press the Mode Select-button, until the Chase/Scenes-LED is lit.
Pull the Speed-fader to minimum.
Press the Step-button in order to insert the step at the desired position.
Press the Insert-button in order to add the step.
Press and hold the Record-button and press the Rec Exit-button in order to leave the editing mode.
Delete a scene/chaser
Press the Mode Select-button, until the Chase/Scenes-LED is lit.
Press and hold the Record-button and press the desired Flash-button in Preset B twice.
The scene/chaser is deleted.
Delete all scenes/chaser
Press and hold the Record-button.
Press the Flash-buttons 1, 4, 2, 3 in Preset A.
Release the Record-button.
All scenes/chaser are deleted.

Clear memory

Press and hold the Record-button.
Press the Rec Clear-button.
Memory is cleared.

Lock program mode

If you want to protect your programs from undesired acces, you can lock the program mode.
Press and hold the Record-button.
Press the Rec Exit-button.
Release the Record-button.
The red LED above the Record-button is off.
Single Chase/Mix Chase
Über die Single Chase/Mix Chase-Taste können Sie den Chaser-Abspielmodus ändern. Im Single Chase-
Modus durchläuft der Controller einen Chaser.
Im Mix Chase-Modus werden alle ausgewählten Chaser gleichzeitig abgespielt.

Switch off individual DMX-channels

You can switch off an individual channel by pressing the Blind-button and the respective Flash-button.
In order to switch the channel on again, press the Home-button and the respective Flash-button.
Set all channels to maximum
Press the Full On-button and all channels will be set to their maximum value. As soon as you release the
button, the channels return to their original setting.
Blackout-Mode
Press the Blackout-button and all devices will be set to Blackout-mode.
