Chaser Mode (only available for the internal programs P 5 and P 6)
This mode enables several slave units after the other so that chaser effects can be operated over several
devices.
You can build up to 126 different slave groups. as an explanation, we give an example with 10 different slave
groups.
Settings for the master device
Adjust the desired internal program P 5 or P 6 at the master device.
Press the MODE button until the display shows SLA.
Press the ENTER button and adjust the A 10 (number of slave groups) via the UP or DOWN buttons. Press
ENTER to confirm.
Setting for the slave devices
Press the MODE button until the display shows SLA.
Press the ENTER button and adjust the desired slave group (here A 1 - A 10) via the UP or DOWN
buttons. Press ENTER to confirm.
SLA
A10 A1
address:
Slave group 1
Setting DMX channel mode
When the display shows __CH, you can select the desired DMX channel mode. Please see the following
table.
Mode:
3 CH
4 CH
5 CH
6 CH
7 CH
9 CH
12 CH
18 CH
36 CH
Setting the DMX starting address
Press the MODE button after selecting the DMX channel mode. You can adjust the desired DMX starting
address by pressing UP or DOWN.
Value:
d 1 - 512
A1 A1 A2 A2 A2
Slave group 2
A2 A3 A3 A3 A3
Slave group 3
32/40
...
A10 A10 A10
...
Slave group 10
