DESCRIPTION OF THE DEVICE

Features

LED color changing bar with 3 W TCLs
• 3, 4, 5, 6, 7, 9, 12, 18, or 36 DMX channels selectable for numerous applications
• Equipped with 12 x 3in1 tricolor LED in the colors red, green and blue
• Each LED can be controlled individually
• Stepless RGB color changing
• Dimmer
• Programmable color change speed and strobe effect
• DMX-controlled operation or stand-alone operation with Master/Slave function
• Color Presets
• Internal programs
• Sound-controlled via built-in microphone
• Microphone-sensitivity adjustable via rotary-control
• Addressing via control panel with 4-digit LED display
• Power connection via Neutrik PowerCon jack and included power cable
• Feed-through output allows to power another device
• After every 8 devices the fixtures must have a renewed connection with the power mains
• DMX control via every standard DMX controller

Overview

4 5
(4) Mounting bracket
(5) Venting slot
(6) Fuseholder
(7) Power input
(8) Power output
(9) DMX-In socket
(10) DMX-Out socket
2 4
(11) Microphone
(12) Mic sensitivity control
(13) Display
(14) Mode button
(15) Up button
(16) Down button
(17) Enter button
26/40
(1) Floor-stand
(2) Fixation screw
(3) LED
6 7 8 9 10
00069076, Version 1.1
4 11 12 13
14 15 16 17
