Channel Mode - Futurelight POS-12 LED TCL POWERSTICK Bedienungsanleitung

Control-channel 5 - Strobe
This channel is only active if channel 6 is set to 0 - 31.
Decimal Hexad. Percentage
0 15 00 0F 0% 6%
16 255 10 FF 6% 100%
Control-channel 6 - Fading in/out, internal programs
Decimal Hexad. Percentage
0 31 00 1F 0% 12%
32 63 20 3F 13% 25%
64 95 40 5F 25% 37%
96 114 60 72 38% 45%
115 127 73 7F 45% 50%
128 159 80 9F 50% 62%
160 191 A0 BF 63% 75%
192 223 C0 DF 75% 87%
224 255 E0 FF 88% 100%
Control-channel 7 – Dimmer
This channel is only active if channel 6 is set to 0 - 31.
Decimal Hexad. Percentage
0 255 00 FF 0% 100%

3 channel mode

Control-channel 1 - Red
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 2 - Green
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 3 - Blue
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
4 channel mode
Control-channel 1 - Red
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 2 - Green
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 3 - Blue
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
Control-channel 4 - Dimmer
Decimal Hexad. Percentage
0 255 00 FF 0% 100%
S/F
S No function
F Strobe-effect with increasing speed
S/F
S Neutral
S Fade in (0%-100%) 7 colors (depending of the channels 1-3)
S Fade out (100%-0%) 7 colors (depending of the channels 1-3)
S Fade out + fade in (100%-0%-100%)
S Internal program "Chase"
S Internal program "Fading 7 colors"
S Internal program "Switching 3 colors"
S Internal program "Switching 7 colors"
S Music control
S/F
F Gradual adjustment of the dimmer intensity from 0 to 100 %
S/F
F Red (0=off, 255=100% red)
S/F
F Green (0=off, 255=100% green)
S/F
F Blue (0=off, 255=100% blue)
S/F
F Red (0=off, 255=100% red)
S/F
F Green (0=off, 255=100% green)
S/F
F Blue (0=off, 255=100% blue)
S/F
F Gradual adjustment of the dimmer intensity from 0 to 100 %
34/40
Feature
Feature
7 colors (depending of channel 1-3)
Feature
Feature
Feature
Feature
Feature
Feature
Feature
Feature
00069076, Version 1.1
