Prosonic FMU 860...862
Transducerblock TB1
Analog Input Block AI2
Endress+Hauser
Der Transducerblock TB1 beinhaltet diejenigen Geräteparameter, die dem Kanal 1
zugeordnet werden können.
Parameter
Standardparameter
Transducer block 1 block object
TB1 Static revision
TB1 Device tag
TB1 Strategy
TB1 Alert key
TB1 Target mode
TB1 Mode block
TB1 Alarm summary
E+H-Parameter
TB1 Measured value Channel 1
TB1 Empty calibration Channel 1
TB1 Full calibration Channel 1
TB1 Application Channel 1
TB1 Type of sensor Channel 1
TB1 Value for 0/4mA Channel 1
TB1 Value for 20mA Channel 1
TB1 Output damping Channel 1
TB1 Measured distance Channel 1
TB1 Measured level Channel 1
TB1 Linearization Channel 1
TB1 Actual level Channel 1
TB1 Q/h curve Channel 1
TB1 Input level Channel 1
TB1 Input volume Channel 1
TB1 Line number Channel 1
TB1 Diameter of vessel Channel 1
TB1 Vmax / Qmax Channel 1
TB1 Low flow cut off Channel 1
TB1 Crest length Channel 1
TB1 Range for auto. suppression Channel 1
TB1 Echo attenuation Channel 1
TB1 Signal / noise ratio Channel 1
TB1 If no echo Channel 1
TB1 Safety alarm Channel 1
TB1 Envelope curve statistics Channel 1
TB1 FAC threshold Channel 1
TB1 FAC rise Channel 1
TB1 Device tag Channel 1
TB1 Unit Channel 1
TB1 Text Channel 1
TB1 View1
Der Analog Input Block AI2 enthält den Messwert des zweiten Kanals und ist mit dem
Transducerblock TB2 verbunden. Er enthält folgende Parameter:
Parameter
Standardparameter
Analog input block 2 block objekt
AI2 Static revision
AI2 Device tag
AI2 Strategy
AI2 Alert key
AI2 Target Mode
AI2 Mode block
AI2 Alarm summary
Kapitel 11: PROFIBUS-DP-Schnittstelle
E+H Matrix Slot Index Size
(CW II) [bytes]
1 120 20
1 121 2
1 122 32
1 123 2
1 124 1
1 125 1
1 126 3
1 127 8
V0H0 1 128 4
V0H1 1 129 4
V0H2 1 130 4
V0H3 1 131 1
V0H4 1 132 1
V0H5 1 133 4
V0H6 1 134 4
V0H7 1 135 4
V0H8 1 136 4
V0H9 1 137 4
V2H0 1 138 1
V2H1 1 139 4
V2H2 1 140 1
V2H3 1 141 4
V2H4 1 142 4
V2H5 1 143 1
V2H6 1 144 4
V2H7 1 145 4
V2H8 1 146 4
V2H9 1 147 4
V3H0 1 148 4
V3H1 1 149 2
V3H2 1 150 1
V3H3 1 151 1
V3H4 1 152 1
V3H5 1 153 1
V3H6 1 154 1
V3H7 1 155 1
VAH0 1 156 16
VAH3 1 157 1
VAH7 1 158 1
1 159 13
E+H Matrix Slot Index Size
(CW II) [bytes]
2 16
2 17 2
2 18 32
2 19 2
2 20 1
2 21 1
2 22 3
2 23 8
Type Read Write Storage
Class
DS32* x C
unsigned16 x N
Octet String(32) x x S
unsigned16 x x S
unsigned8 x x S
unsigned8 x x S
DS37* x D
DS42* x D
floating point x D
floating point x x S
floating point x x S
unsigned8 x x S
unsigned8 x x S
floating point x x S
floating point x x S
floating point x x S
floating point x D
floating point x D
unsigned8 x x S
floating point x x S
unsigned8 x x S
floating point x x D
floating point x x D
unsigned8 x x D
floating point x x S
floating point x x S
floating point x x S
floating point x x S
floating point x x S
integer16 x S
unsigned8 x S
unsigned8 x x D
unsigned8 x x D
unsigned8 x x S
unsigned8 x x S
unsigned8 x x S
Octet String(16) x x S
unsigned8 x x S
unsigned8 x x S
OSTRING x D
Type Read Write Storage
Class
DS32* x C
unsigned16 x N
Octet String(32) x x S
unsigned16 x x S
unsigned8 x x S
unsigned8 x x S
DS37* x D
DS42* x D
