Power supply:
230 V/50 Hz
Power consumption:
1500 W, Fuse: T10A
Lamp:
HMI/MSI 1200W
Optical System
- Double condensor lens with high efficiency parabolic mirror, focus lens and multistep zoom lenses system
(15°, 21°, 28° beam angles)
Colours
Colour wheel 1:
- 8 dichroic-filters plus white, colour-wheel with variable rotation speed
Colour wheel 2:
- 5 dichroic-filters, colour temperature filters 3200 K and 5600 K, UV filter plus white,
Static gobos
- 5 metal gobos plus full circle
- static gobo wheel cont. rotation
Rotating gobos
- 2 metal gobos, 1 glass gobo and 1 multicolor dichroic gobo rotating in both dirrections at different speeds
- gobo indexing
Strobe
- Strobe effect with variable speed (1 - 10 flashes per second)
Dimmer
Smooth dimmer from 0 - 100%
Effects
- 3-facet prism, 5-facet prism, 5-linear facet prism, rotating in both dirrections at different speeds
- 5-linear facet prism indexing
- Wash light filter (frost)
Iris
Motorized iris for different beam diameters
Focus - multistep zoom
Motorized focus enables the beam to be focused anywhere on stage at different beam angles: 15°, 21°, 28°,
provided by the special multistep zoom (3 steps).
Motor
- 14 high quality stepper motors controlled by microprocessors
Electronics
- Digital serial input DMX-512
- 16 control-channels (full 16 bit protocol):
Channel 1: Horizontal mirror-movement 8 bit
Channel 2: Vertical mirror-movement 8 bit
Channel 3: Fine Horizontal mirror-movement 16 bit
Channel 4: Fine Vertical mirror-movement 16 bit
Channel 5: Pan/Tilt speed
Channel 6: Fan speed, On/Off lamp, reset
Channel 7: Colour 1
Channel 8: Colour 2
Channel 9: Effects - rotating prisms, wash light
Channel 10: Static gobos
Channel 11: Rotating gobos
Channel 12: Gobo rotation, gobo indexing
Channel 13: Iris
Channel 14: Focus - multistep zoom
Channel 15: Shutter, strobe
Channel 16: Dimmer
