Invertek Drives OPTIDRIVE P2 Benutzerhandbuch Seite 12

3.4.2. IP55 Units
Drive A B
Size
mm in mm
4 450 17.72 428 16.85
5 540 21.26 515 20.28
6 865 34.06 830 32.68
7 1280 50.39 1245 49.02
Mounting Bolts
Frame Size 4 : M8 (5/16 UNF)
Frame Size 5 : M8 (5/16 UNF)
Frame Size 6 : M10 (3/8 UNF)
Frame Size 7 : M10 (3/8 UNF)
Tightening Torques
Control Terminal Torque Settings :
Power Terminal Torque Settings :
12
Optidrive ODP‐2 User Guide Revisions 1.30
C D
in mm in mm in
433 17.05 8 0.31
520 20.47 8 0.31
840 33.07 10 0.39
1255 49.41 10 0.39
All Sizes : 0.8 Nm (7 lb‐in)
Frame Size 4 : 4 Nm (3 lb‐ft)
Frame Size 5 : 15 Nm (11.1 lb‐ft)
Frame Size 6 : 20 Nm (15 lb‐ft)
Frame Size 7 : 20 Nm (15 lb‐ft)
www.invertekdrives.com
E F G
mm in mm in mm
240 9.45 171 6.73 110
270 10.63 235 9.25 175
330 12.99 330 12.99 200
360 14.17 330 12.99 200
H I
in mm in mm in
4.33 4.25 0.17 7.5 0.30 11.5
6.89 4.25 0.17 7.5 0.30 22.5
7.87 5.5 0.22 11 0.43
7.87 5.5 0.22 11 0.43
Weight
kg lb
25.4
49.6
50 110.2
80 176.4
