10.1 Wiring diagram
for AS 11 S, AS 14, AS 14 S
Item Designation
59 Fuse (front and rear work
lights)
60 Fuse (rear window heater)
61 Fuse (heating, fan)
62 Fuse (drive operation, elec-
tronic control, left and right
rear light, reverse alarm)
63 Monitoring lamps unit
64 Operating hours meter
65 Fuse (monitoring lamps unit,
instrument panel, brake light)
66 Gear indicator, digital speed-
ometer, error display
67 Fuel gauge
68 Cooling water temperature
gauge
69 Relay for reversing lights, re-
verse alarm (option)
70 Drive switch
71 Brake light switch
72 Reverse light, right
73 Reverse light, left
74 Reverse alarm
75 Dip pipe sensor
76 Water temperature sensor
77 Brake light, left
78 Brake light, right
79 Valve, gear shift synchroni-
zation
80 Forward valve drive direction
81 Reverse valve drive direction
82 Speed sensor, drive
83 Speed sensor, hydro motor
84 Valve, parking brake
85 Valve, gear shift, 2nd gear
86 Valve, gear shift, 1st gear
87 Electronic controller
GB
Item Designation
88 Cravler valve (only AS 14)
89 Control pressure sensor
90 Voltage divider
91 Switch, neutral
92 Switch, water level low
93 Switch, water temperature
94 Switch, service brake failure
95 Switch, hydraulic oil filter
96 Switch, engine oil pressure
97 Fan motor, heater
98 Rear screen heater
99 Work light, rear
100 Work light, front
S11C/S13C
