IMPAC pyrometers series IN 5 plus
Error status:
Reading parameter:
1)
Device address :
Baud rate:
Internal pyrometer
temperature:
Max. internal pyrometer
temperature:
1)
Reset :
Command delay:
Reading ambient
temperature:
Entering ambient
temperature:
Marginal values for ambient
temperature:
Reading maximum/minimum
values:
Setting maximum/minimum
values:
Reading marginal values:
Serial number:
Device model / software
version:
Note: the letter "l" means the lower case letter of "L".
1)
After entering these commands the device carries out an automatic reset. The device needs
approx. 150 ms before it is ready to use and work with the changed settings.
Additional instruction for the RS485 interface:
Requirements to the master system during half-duplex operation:
1. After an inquiry, the bus should be switched into a transmission time of 3 bits
(some older interfaces are not fast enough for this).
2. The pyrometer's response will follow after 5 ms at latest.
3. If there is no response, there is a parity or syntax error and the inquiry has to be repeated.
AAfs Output 1 Byte hex
Bit 0 = 1: EEPROM error
Bit 1 = 1: Watch dog Reset
Bit 2 = 1: Under voltage reset
AApa Output 11-digit decimal:
Digit 1 and 2 (20 to 99 or 00): emissivity
Digit 3 (0 to 6): t
Digit 4 (0 to 8): t
Digit 5 (0 to 1): analog output
Digits 6 and 7 (00 to 98): temperature
Digits 8 and 9 (00 to 31): address
Digit 10 (0 to 4): baud rate
Digit 11 always 0
AAgaXX XX: Device address decimal
00 to 31 variable device addresses
AAbrX X = 0 to 4
0: 1200 Bd
1: 2400 Bd
AAgt Output: XX (dec. 00 to 98, in °C)
AAtm Output: XX (dec. 00 to 98, in °C)
AAre Reset device
AAtwXX XX = 00 to 20 relative delay value
AAut Output: stored value, 4-digit hex
e.g. 0258 corresponds to 600 degrees
AAutXXXX XXXX = value of ambient temperature, 4-digit, hex
XXXX e.g. FFEC corresponds to –20 degrees
- 99
dez
compensation
AAut? Output: marginal values for the entry, 2 x 4-digit, hex
e.g. FF9D0384 corresponds to -99 to 900 degrees
AAmi Output: 0 or 1
0 = maximum value, 1 = minimum value
AAmiX X = desired setting
0 = maximum value, 1 = minimum value
AAmi? Output: marginal value for entry, always 01
AAsn Output: XXXXX (5-digit decimal)
AAve Output: XXYYZZ (6-digit decimal)
(exposure time)
90
(storage delete mode)
CL
2: 4800 Bd
3: 9600 Bd
= FF9D means: automatic, no manual
hex
XX = 70 (IN 5 plus)
71 (IN 5/5 plus)
YY = month of the software version
ZZ = year of the software version
4: 19200 Bd
