1 0 . F 1 C - A r e d u c t i o n a s s e m b l y - slow speed shaft with crossroller bearing
The safety instructions given before, item 6 to 7, are very important, please observe every single item.
Non-observance may cause injuries, machine damage or the warranty may lapse.
10.1 F1C-A installation and assembly procedure
The FINE CYCLO reduction assemblies F1C-A are supplied ready for mounting.
Each reduction assembly is greased before the test run and supplied ready for use and suitable for any
mounting position.
The FINE CYCLO reduction assemblies Type F1C-A are shipped without painting.
Fit the slow speed flange solidly to the driven shaft of machine. Tighten fixing bolts firmly according to
the instructions on tab. 1.
The motor can be mounted to the input flange by use of a suitable adaptor (see mounting examples
shown at the Precision catalogue No. 991007).
In the case of standard speed reducers with hollow high speed shafts and keyway, MoS
(e.g. Molykote) is to be applied to the motor shaft. When locking ring is used at the input shaft, connec-
tions must be free of oil or grease.
10.2 F1C-A allowable transmitted torque
Allowable transmitted torque (refer to Tab. 1) could be limited by mounting bolts. The recommended bolt
grade, quantity, size and tightening torques for the output flange and ring gear housing are shown in Tab. 1.
Tab. 1

F1C-A

Number of
15
25
35
45 G
65 G
75 G
* Screw grade 12.9 - all screws to be used!
10.4 F1C-A lubrication and maintenance
The FINE CYCLO reduction assemblies F1C-A sizes 15 to 35 are lifetime grease lubricated (ESSO
UNIREX N2) and suitable for any mounting position.
The cross roller bearings of F1C-A sizes 45G, 65G and 75G require regreasing every 4,000 running
hours. For quantities and type of lubricant for the crossroller bearings see Tab. 2.
Quantities of lubricant should be adjusted according to the ambient conditions. The quantities shown in
tab. 2 should be used as a reference point for clean, dry rooms.
The bearings should be rotated during lubrication to ensure that the lubricant is distributed evenly.
We recommend the unit is returned to Sumitomo Drive Technologies for inspection and regreasing after
5 years to increase service lifetime.
Tab. 2 Lubricant, grease quantity for relubrication of cross roller bearings
F1C-A
45 G SHELL ALVANIA EPLF2
65 G SHELL ALVANIA EPLF2
75 G
* no longer than 6 months
Please observe legal /environmental regulations when handling grease or other chemicals.
FC_GB_01_05 NO.991051
F I N E C Y C L O O p e r a t i n g M a n u a l
Slow speed shaft bolts
Bolt size Tightening
bolts DIN 4762 torque *[Nm]
12 M6 16
12 M8 39
12 M10 77
12 M14 210
16 M16 330
16 M16 330
Lubricant
ESSO BEACON EP2
Ring gear housing bolts
Number of Bolt size Tightening torque
bolts DIN 4762
12 M6
12 M8
12 M10
16 M10
20 M12
20 M12
Initital lubrication Subsequent lubrication
~ 23 g
~ 62 g
~ 108 g
Issue: 01/05
paste or spray
2
Allowable transmitted torque
by bolts [Nm] T2t
*[Nm]
16 750
39 1700
77 3150
77 3550
135 7000
135 8000
time period
~ 10 . 15 g 4.000 h *
~25 - 30 g 4.000 h *
~45 - 50 g 4.000 h *
Page 9
