Wiring Diagrams - EOS 46.U compact Montage- Und Gebrauchsanweisung

Wiring diagrams

4,5 - 7,0 kW
Saunasteuergerät
Control unit
Boîtier de commande
5
Netz / Mains / Réseau /
U V W N PE
U V W N PE
Electrical. Fuse control
elektr. Anschluss
Connection unit in A
4,5 kW
3N AC
6,0 kW 50 Hz 3 x 16
400 V
7,5 kW
All cross sections of a line are minimum diameters in mm² (Copper line)
20
Saunaheizgerät
Sauna heater
Poêle de sauna
4
5
4,5 kW
6,0 kW
(6x1000 W)
Minimum
Installation dimensions
For cabin
dimensions of air intake
size
H/W/D cm and exhaust
vents
4 - 6 m³ 35 x 4 cm
87 / 92 / 20 6 - 8 m³ 35 x 4 cm
7 - 10 m³ 35 x 5 cm
CAUTION!
Make sure the neutral wire is
connected.
U V W N PE
U V W N PE
Connecting
Weight without
Stone cable main
stones without
filling - control unit
package
in mm²
ca. 20 kg 10 kg 5 x 2,5²
GB
6,0 kW
(4x1500 W)
7,5 kW
Connecting Power
cable control switch For operation with control
unit - heater gear (LSG) units
in mm² needed
ECON D1, D2, D3, D4
ECON H1, H2, H3, H4
5 x 1,5² nein EMOTEC D
EMOTEC H
EmoToch II+
