Connection and start-up

The CWF Multi unit can be used together with a
PI 320/350/400/500 or a PI PLASMA in configurations
requiring cold wire feeding.
More than one unit can be connected to PI but only one can
be active at a time.
Warning
Read warning notice and instruction
manual carefully prior to initial
operation and save the information
for later use.
Connection
4
CWF
m
min
Multi
S
m
min
1. CAN plug
2. CAN plug
3. Wire inlet
4. Remote control plug
Cable length
Note!
Use rubber feet (45070026) as galvanic separator between the
CWF casing and the unit on which it is mounted.
1 2 3
Error codes
When the CWF is connected to the power source, the
following error codes can be displayed in the display:
Technical data
Wire feed speed, m/min
Wire dimension, mm
Dimensions (HxWxL), mm
Standards
Weight, kg
Protection class
1
Equipment marked IP23 is designed for indoor and outdoor
1)
applications
Motor overload
Motor control malfunction
Problems on control of wire feed speed
Identical ID on more than one CWF connected to PI.
Change the ID.
130
M6
0.2-5.0
0.6-2.4
276x211x276
IEC60974-5.
IEC60974-10 CL. A
9.6
IP23
11
