Eaton S811 Soft Starter Handbuch Seite 25

Abmessungen in Zoll (mm)
Abbildung 6: S811+V...
6.79 (172.5)
9.84 (250.0)
11.05 (280.6)
0.236
(6.00)
15.63
(397.0)
3.05
(77.5)
7.39
(187.8)
6.50
(165.1)
0.2650
4X Ø
(6.731)
S811 Softstarter MN03900001E—Mai 2013
16.57
(420.8)
www.eaton.com
Installation
13
