4.2 Abmessungen

Abmessungen in Zoll (mm)
Abbildung 2: S811+N...
1.97 (50.0)
6.87
(174.5)
0.22
4X Ø
(5.5)
Abbildung 3: S811+R...
3.54 (90.0)
4X Ø
6.45 (163.9)
7.44
(189.0)
0.27
6.64 (168.6)
(6.8)
S811 Softstarter MN03900001E—Mai 2013
2.66
(67.6)
7.37
(187.2)
3.32
(84.4)
7.92
(201.2)
3.49
(88.5)
www.eaton.com
Installation
5.89
(149.7)
5.35
(135.9)
4.38 (111.3)
6.08
(154.5)
5.54
(140.7)
11
