3.2 Installing the front wheel
1. Fit the front wheel into the dropouts of the fork.
Make sure to install the front wheel in accordance with the
tyre's rotational direction. The direction arrow is moulded into
the side casing.
2. Tighten the axle bolts to a torque of 5 Nm with a 5 mm hex
wrench.
3.3

Installing the rear wheel

1. Fit the rear wheel into the dropouts.
Make sure to install the rear wheel in accordance with the
tyre's rotational direction. The direction arrow is moulded into
the side casing.
2. Tighten the axle bolts to a torque of 5 Nm with a 5 mm hex
wrench.
3.4 Installing handlebar and stem
1. Place the handlebar and stem on the steerer.
The handlebar/stem combination can be fitted in two different
positions. We recommend to assemble it in the high position.
2. Put the top cap with the adjusting bolt on the stem.
3. Tighten the adjusting bolt (1) finger-tight.
4. Check for headset play and adjust it, if need be.
5. Tighten the stem clamps (2) to a torque of 3 Nm.
1
2
11
