Electrical data
The accuracies indicated refer to the value measured and are defi-
ned for 23°C +/- 5°C and < 80% RH
Alternating current A.C. (Autorange)
Measuring range
Resolution Accuracy (50Hz - 500Hz) Overload protection
10A
1mA
100A
10mA
Direct current D.C. (Autorange)
Measuring range
Resolution Accuracy (50Hz - 500Hz) Overload protection
10A
1mA
100A
10mA
A.C. voltage AC
Measuring range
Resolution Accuracy (50Hz - 500Hz) Overload protection
600V
0.1V
D.C. voltage DC
Measuring range
Resolution Accuracy (50Hz - 500Hz) Overload protection
600V
0.1V
Resistance (Ω)
Measuring range Resolution Accuracy Max. test voltage Overload protection
10kΩ
1Ω
1% + 3 digit
Continuity (
)
Measuring range
Active from
< 100Ω
Analog output (for A.C. A and D.C. A)
- 10mV / Ampere (20 kHz +/- 3 dB)
- Accuracy +/- 2,5% + 0,5 mV)
- Output impedance abt. 3 Ω
- Overload protection 600 V rms
28
2% + 10 digit
150A rms
2.5% + 10 digit
150A rms
1.5% + 5 digit
660V rms
1% + 2 digit
660V rms
3V DC
660V rms
Max. test voltage
Overload protection
3V DC
660V rms
Any use other than the one described above damages
the product. Moreover, this involves dangers, such as
e.g. short-circuit, fire, electric shock, etc. No part of the
product may be modified or rebuilt.
Always observe the safety instructions!
Safety instructions
In case of any damage which is caused due to failu-
re to observe these operating instructions, the gua-
rantee will expire. We do not assume liability for
resulting damage.
An exclamation mark housed in a triangle refers to important
indications in the operating instructions. Read the instructions
completely before putting the instrument into service.
The unauthorised conversion and/or modification of the product is
inadmissible because of safety and approval reasons (CE).
Never exceed the maximum input values.
Never use the instrument when it is defective. Test the instrument
for its proper operation prior to any use.
Never measure resistances or continuities on components which
are under a current/tension.
Be particularly careful with voltages exceeding 25 V A.C. or 35 V
D.C. In case of a contact, it is already with these voltages that you
could suffer an electric shock which is dangerous to your life.
When making measurements, never put your finger over the protec-
tive shroud.
In commercial and industrial facilities, the regulations for the pre-
vention of accidents as laid down by the professional trade associa-
tion for electrical equipment and devices need to be observed.
Keep the instrument out of the reach of children.
